Product Overview

The ABB PM866K01 is a central processing unit (CPU) that serves as the core component of the AC 800M series, designed for real-time processing of complex control logic and monitoring tasks. It features a modular design for easy installation and maintenance, with excellent compatibility with other ABB products.

Technical Specifications

• Processor: Dual-core ARM Cortex-A9 processor, running at 800 MHz.
• Memory: 4GB eMMC storage and 2GB RAM, with support for expandable storage.
• Communication Interfaces: Supports multiple protocols, including Ethernet, Modbus TCP/IP, PROFIBUS, and DeviceNet.
• Input/Output (I/O): Capable of handling up to 2048 digital I/Os and 512 analog I/Os.
• Operating Temperature Range: -20°C to +60°C.
• Power Supply: Typically operates on 24V DC, with some models supporting AC power.
• Dimensions: Standard module size of 239mm × 80mm × 35mm, weighing approximately 0.72kg.

Applications

The ABB PM866K01 is widely used across multiple industrial sectors, including but not limited to:

• Manufacturing: Control of automated production lines.
• Energy Sector: Critical equipment monitoring in power plants and energy facilities.
• Chemical, Oil & Gas Industries: Precision control for complex processes.
• Other Industries: Such as water treatment, mining, and transportation.

Key Features & Benefits

• High Performance: Dual-core ARM Cortex-A9 ensures fast response and reliable operation.
• Flexibility: Supports multiple communication protocols and I/O configurations for easy system expansion and maintenance.
• Reliability: Built with industrial-grade components for harsh industrial environments.
• Modular Design: Simplifies installation and maintenance while ensuring compatibility with other ABB products.
