AEG 6058-042.248263

The AEG 6058-042.248263 is a PanelMate Plus operator interface designed for industrial machine monitoring and control. It provides a practical HMI platform between operators and automation equipment, allowing process information to be displayed and control commands to be entered from a dedicated operator panel. Public product listings identify it as a Modicon AEG PanelMate operator interface, and related records associate it with part number 92-00757-02.

Product Highlights

This operator interface is intended for industrial environments where clear visualization and convenient operator access are required. In addition, the PanelMate architecture allows the HMI to work as part of an established automation system.

Furthermore, this product is associated with the PanelMate Plus family and is commonly categorized as an HMI, MMI, or operator interface. Therefore, it can be considered for machine control stations, production equipment, and legacy industrial control applications.

Technical Information

Available product records describe the unit as a 10-inch PanelMate operator interface. Some secondary listings also report a color TFT LCD, 800 × 480 resolution, and touchscreen operation. However, these specifications are not consistently documented across independent sources, so they should be verified against the actual unit or original technical documentation before installation.

Other commonly associated information includes:

• Product family: PanelMate Plus
• Product category: HMI / operator interface
• Display class: 10-inch class
• Application: Industrial machine monitoring and control
• System role: Operator visualization and command interface
• Related identification: 92-00757-02
• Power versions: Different listings associate the family with 18–28 VDC and 18–30 VDC configurations, so the exact power requirement should be confirmed before replacement.

Interface and System Integration

The unit functions as the operator-facing layer of an automation system. First, process information can be presented in an accessible visual format. Next, operators can use the interface to monitor equipment conditions and interact with configured control functions.

Moreover, an HMI of this type can simplify communication between personnel and PLC-based control equipment. As a result, operators can work with production information without directly accessing internal controller hardware.

For legacy installations, compatibility remains particularly important. Therefore, the communication method, application configuration, power arrangement, and connected controller should all be checked before integration.

Typical Applications

This type of operator interface can be used in a wide range of industrial control environments. For example, typical applications include:

• Manufacturing machinery
• Production lines
• Process control equipment
• Packaging systems
• Material handling equipment
• Machine operator stations
• Legacy PLC installations

In addition, it can be useful when maintaining older automation equipment where the existing HMI architecture is still required for daily operation.

Installation and Maintenance

Before installation, verify the panel cutout, mounting arrangement, power requirements, and communication connections. In particular, different versions within the product family may use different electrical configurations, so the nameplate and existing system documentation should be checked carefully.

After mounting, inspect all cables and connectors before energizing the equipment. Furthermore, confirm that the connected controller and HMI configuration are compatible. If communication is unavailable after installation, check the power supply first, followed by the communication wiring and controller settings.

Regular maintenance should include cleaning the display surface with appropriate materials and checking the enclosure for damage. Additionally, technicians should inspect connectors for looseness and examine the panel for signs of excessive heat, moisture, or physical wear.

Replacement Considerations

The product is identified in current repair and resale databases as a legacy or discontinued operator interface. Consequently, sourcing a replacement may require attention to exact identification and system compatibility.

When replacing an existing unit, technicians should compare the electrical rating, display configuration, communication interfaces, mounting dimensions, and application requirements. Finally, a complete functional test should be performed after installation to confirm proper communication and operator control.
