Allen-Bradley 1336S-B007-AN frequency converter module
Allen-Bradley 1336S-B007-AN
1. Overview
The Allen‑Bradley 1336F‑BRF50‑AN is part of Rockwell Automation’s 1336 PLUS II Series of AC adjustable frequency drives. Renowned for high reliability, flexible control, and easy integration, this series is widely used in diverse automation systems, especially in industrial applications requiring precise torque control.
2. Specifications
- Rated Power: 0.75 kW (approximately 1 HP)
- Rated Output Current: 5.5 A
- Input Voltage: 200–240V AC (single‑phase)
- Output Voltage: 0V – 240V AC
- Frequency Range: 0.5 Hz – 150 Hz
- Operating Temperature: -10°C to +40°C
- Storage Temperature: -20°C to +60°C
- Dimensions: Approximately 230mm x 130mm x 45mm
- Weight: Approximately 2.5 kg
_____________________
3. Key Features
- Compact Modular Design: Compared to traditional bulky drives, the 1336 Series uses a modular structure that is smaller, lighter, and easier to install and maintain.
- Multi‑Language / Protocol Support: Built‑in language modules (such as AN, AA) and compatibility with protocols like Modbus RTU and PROFIBUS DP enable seamless integration with PLCs and host systems.
- Intelligent Parameter Tuning: Offers extensive parameter options and supports standard motor profiles (NEMA, IEC), allowing engineers to configure quickly.
- High Efficiency & Low Harmonics: Advanced vector control technology delivers high power factor and low harmonic distortion, meeting energy‑saving standards.
- Comprehensive Protection: Includes overcurrent, overvoltage, overtemperature, and other protection mechanisms to ensure safe operation of motors and equipment.
_________
4. Structure & Components
- Power Supply Module: Converts input voltage to internal working voltage and provides DC power to the inverter bridge.
- Power Module: Consists of IGBT or MOSFET semiconductors that form the inverter bridge and directly drive the motor.
- Control Unit: Features a built‑in microprocessor that runs control algorithms such as V/Hz and vector control.
- Communication Interfaces: Equipped with RS485, Ethernet, and optional protocol modules (AN, AA).
- Display & Keypad: Includes an LCD screen and keyboard for parameter setup, fault diagnosis, and status monitoring.
__________
5. Applications
- Industrial Automation: Commonly integrated with PLC systems to drive conveyors, pumps, fans, compressors, and other machinery.
- Process Control: Used in chemical, pharmaceutical, and food industries for fluid transfer and mixing control.
- Energy Management: Applied in high‑efficiency pump and fan systems to reduce energy consumption.
- Specialized Applications: Its precise torque control makes it suitable for textiles, packaging, and other industries requiring high‑accuracy speed regulation.
__________
6. Installation & Maintenance
Installation Notes
- Ventilation & Heat Dissipation: Ensure ventilation slots are unobstructed and allow sufficient space for air circulation.
- Power Isolation: Use shielded cables between the drive and motor, and ensure proper grounding to minimize electromagnetic interference.
- Moisture & Dust Protection: Avoid installation in dusty, humid, or corrosive environments.
Regular Maintenance
- Periodic Inspections: Check ventilation and heat sinks every 3–6 months and remove accumulated dust.
- Parameter Backup: Before making major parameter changes, back up the original settings using a USB storage device.
- Troubleshooting: The display provides fault codes; refer to the user manual for troubleshooting guidance.
————————————————————————————————————-
