GE DS200DCFBG1NC

1. General Description

2. Parameters

• Input Voltage: 38 VDC or 115 VAC
• Output Voltage: 24 VDC
• Rated Current: 10 A
• Analog Output: 4-20 mA analog output
• Operating Temperature: -40°C to +70°C
• Storage Temperature: -40°C to +80°C
• Transportation Temperature: -40°C to +80°C
• Humidity: Up to 95% (non-condensing) during operation; 5% to 95% non-condensing at 55°C
• Dimensions: 100mm × 80mm × 50mm
• Weight: 200g

3. Product Features

• High Reliability: Uses industrial-grade components, ensuring high reliability and stability, suitable for harsh industrial environments.
• Modular Design: Facilitates maintenance and replacement, reduces maintenance costs, and improves system scalability.
• Versatility: Provides power for multiple components of the control system, including the system control level and enclosure fans.
• Strong Compatibility: Compatible with various drives in the GE Mark V series, such as FC2000, AC2000, DC2000, ME2000, and CB2000.
• High Efficiency: Efficiency greater than 90% with an output power of up to 4.8kW.
• Easy Installation and Maintenance: High configuration flexibility, allowing users to configure via jumpers and DIP switches.

4. Structure and Composition

• Circuit Integration: Includes drive circuits, control-level power supply circuits, motor field power supply circuits, and AC/DC monitoring circuits.
• Fuse Protection: Equipped with three fuses for protection to ensure uninterrupted circuit operation.
• Indicators and Test Points: Integrated LED and neon indicators alert users to any fuses requiring attention, while five test points allow for monitoring voltage levels.
• Communication Interfaces: Supports multiple communication interfaces such as Ethernet, RS-232, and RS-485, facilitating data exchange and communication with other devices.

5. Application Fields

• Power Industry: Used for turbine control in power systems such as thermal power plants and nuclear power plants.
• Petrochemical Industry: Applied in turbine control during petrochemical production processes.
• Other Industrial Fields: Widely used in industrial sectors requiring high-reliability control systems, including oil and gas, chemicals, water treatment, wastewater treatment, metals, mining, pulp and paper, rubber and plastics, and textiles.
• Motor Applications: Includes pumps, fans, compressors, conveyors, machine tools, cranes, elevators, and escalators.

6. Installation and Maintenance

• Installation Methods: Typically installed using DIN rails or screw fixation.
• Installation Steps:
  • Ensure the installation environment meets the product’s operating temperature and humidity requirements.
  • Install the power board in a suitable location with good ventilation.
  • Connect the power cables and signal lines, ensuring secure connections.
  • Configure the power board parameters, such as IP address, subnet mask, default gateway, DNS server, MAC address, module name, CPU priority, and SNMP configuration.
• Maintenance Recommendations:
  • Regularly check the power board’s connections and indicator status.
  • Clean the surface of the power board to prevent dust accumulation.
  • Periodically test the output voltage and current of the power board to ensure normal operation.
  • If abnormalities are found, contact professional technicians for repair in a timely manner.

————————————————————————————————————-
