EMERSON KJ3243X1-BK1 Digital/Auxiliary Input Module
EMERSON KJ3243X1-BK1
1. Overview
2. Specifications
| Specification | Description |
|---|---|
| Power Supply Voltage | 24 V DC |
| Power Consumption | 12 V DC @ 300 mA (Local Bus Power) |
| Weight | Approximately 0.2 kg |
| Operating Temperature Range | -20 ℃ ~ +60 ℃ (Meets industrial on-site requirements) |
| Interface Type | Compatible with DeltaV 12P Series Bus (PROFIBUS DP/Modbus TCP) |
| Signal Channels | 8-channel digital input (dry contact) or 8-channel analog input (4-20 mA / 0-10 V) |
| Environmental Protection | IP20 (Indoor Installation) |
3. Product Features
- Easy Installation: Modular design enables plug-and-play installation and simplifies on-site wiring.
- Strong Compatibility: Supports a variety of on-site instruments and sensors, and is compatible with DeltaV 2 Plus Series control stations.
- High Data Throughput: Meets the requirements of process control for high-speed and reliable signal acquisition.
- High Reliability: Adopts industrial-grade components, featuring anti-interference and anti-vibration capabilities, suitable for harsh environments.
- Convenient Maintenance: Indicator lights show working status, enabling quick location of faults during diagnosis.
4. Structure and Composition
- Base (12P2531X102): Provides power supply, signal bus, and mechanical support.
- Module Body: Integrates 8-channel input circuits (digital/analog) inside, equipped with a HART communication chip.
- Terminal Block: Each channel is equipped with signal, grounding, and HART interfaces for easy on-site wiring.
- Heat Sink: Metal heat sink improves heat dissipation performance and ensures stability during long-term operation.
- Status Indicator Lights: Display power supply, communication, and fault statuses.
5. Application Fields
- Process Control: On-site signal acquisition for continuous production processes in chemical, petroleum, pharmaceutical, and other industries.
- Manufacturing Automation: Sensor input for assembly lines in automotive, electronics, and other industries.
- Building Automation: Status monitoring of facilities such as lighting, air conditioning, and elevators.
- Power Industry: Monitoring of operating parameters of generator sets and substations.
6. Installation and Maintenance
Installation Steps
- Turn off the power of the control station and confirm that the bus is de-energized.
- Insert the module into the corresponding 12P slot and ensure the buckle is securely fastened.
- Connect the on-site instrument signal lines, grounding lines, and power lines according to the wiring diagram.
- Start the control station and check if the module indicator lights work normally.
Maintenance Points
- Regularly check the tightness of the terminal block to prevent signal distortion caused by loosening.
- Perform online diagnosis through DeltaV engineering software to check the module status and error codes.
- If abnormal indicator lights or communication interruptions are found, first check the power supply and bus connections, then replace the faulty module.
————————————————————————————————————-
