TRICONEX 3502E

1. Overview

The TRICONEX 3502E is a digital input module based on TMR (Triple Modular Redundancy) technology, supporting 48V AC/DC voltage input and featuring self-test functionality. Designed for industrial automation systems, it delivers high reliability and safety, making it suitable for critical applications such as:

• Emergency Shutdown (ESD)
• Burner Management System (BMS)
• Fire & Gas System (F&G)
• High Integrity Pressure Protection System (HIPPS)
• Turbomachinery Control (TMC)

Its modular design enables easy configuration and expansion, enhancing system flexibility and scalability.

2. Key Parameters

3. Product Features

• High Reliability: TMR technology ensures robust performance in critical applications.
• Modular Design: Simplifies configuration and system scalability.
• Self-Test Capability: Detects “stuck” faults in circuits automatically.
• Strong Compatibility: Supports multiple protocols with advanced diagnostics.
• High Integration: Pre-integrated software enables seamless 2D/3D HMI clusters, splash screens, rear-view cameras, and panoramic applications.
• Virtualization: Developers can integrate reference solutions without modifying existing Linux/Android applications.

4. Structure & Design

The TRICONEX 3502E adopts a triple-redundant architecture, where each I/O point is processed by three independent channels. This ensures uninterrupted operation even if one channel fails. Key components include:

• Power inputs (PWR, PS1, PS2) and ground (PWR-), connected to the backplane.
• Input ports with bridge rectifiers, AC smoothing filters, and opto-isolators for signal stability.
• Three internal test points (Test A/B/C) for self-verification.

5. Applications

The TRICONEX 3502E is widely used in:

• Emergency Shutdown (ESD): Rapid process halting during emergencies.
• Burner Management System (BMS): Combustion process control.
• Fire & Gas System (F&G): Leakage and fire detection.
• HIPPS: Pressure safety in critical equipment.
• Turbomachinery Control (TMC): Turbine monitoring.
• Industrial Automation: Digital signal acquisition and processing.

————————————————————————————————————————–
