TRICONEX 3805H

1. Overview

The TRICONEX 3805H is a high-performance analog output module designed for industrial process control, offering high reliability, precision, and flexibility. It converts digital signals into standard 4-20mA analog signals to drive actuators (e.g., valves, motors) for precise control. Featuring a Triple Modular Redundancy (TMR) architecture, the module ensures high availability and safety in mission-critical applications.

-

2. Key Parameters

-

3. Product Features

• High Reliability: TMR architecture ensures continuous operation even if a single module fails.
• High Precision: 12-bit resolution and <0.25% accuracy guarantee stable signal output.
• Flexibility: Supports multiple communication protocols and configurable options for diverse industrial environments.
• Modular Design: Easy expansion and maintenance for complex industrial needs.
• Safety Compliance: Meets IEC 61508 functional safety standards and SIL3 requirements.

-

4. Structure and Components

The TRICONEX 3805H consists of:

• Analog Output Channels: 8 isolated 4-20mA current loops.
• Redundant Architecture: Triple redundancy for fault tolerance.
• Communication Interfaces: Modbus, Ethernet, Profibus, etc.
• Power Module: Stable 24V DC input.
• Robust Enclosure: IP67-rated for harsh industrial conditions.

-

5. Applications

The TRICONEX 3805H is widely used in:

• Oil & Gas: Monitoring wellheads, refineries, and pipelines.
• Chemical Industry: Controlling reactors and process parameters.
• Power Generation: Safeguarding power plants and substations.
• Steel Manufacturing: Process automation.
• Nuclear Industry: Safety systems in nuclear power plants.
• Emergency Shutdown (ESD) Systems: Rapid response to hazards.
• Fire & Gas Detection: Critical alarm systems.
• Turbine Control: Precision management of turbines.
