TRICONEX DO 3626X

1. Overview

The TRICONEX DO 3626X is part of the Triconex Safety Instrumented System (SIS) and belongs to the Trident series. It features a Triple Modular Redundancy (TMR) architecture, ensuring continuous operation even in the event of a fault. This module is designed to convert digital signals into physical outputs to control external devices or execute specific actions, such as operating switches, machines, equipment, pipelines, valves, signal lights, and railroad switches. Its design emphasizes high reliability, availability, and advanced diagnostics, making it ideal for industries with stringent safety requirements.

2. Key Parameters

3. Product Features

• High Reliability: TMR architecture ensures fault-tolerant operation.
• Noise Immunity: Optical isolation technology minimizes interference between controllers and loads.
• Flexible Configuration: Supports multiple output types for diverse control needs.
• Online Diagnostics: Comprehensive fault detection and isolation capabilities.
• Hot-Swap Functionality: Enables maintenance without system downtime.
• Compatibility: Seamless integration with other Triconex system modules.
• High Availability: Supports active-high/low outputs for flexible signal control.
• Fast Response: 192 kHz servo rate for rapid reaction times.
• Safety Certification: TÜV Rheinland SIL3 certified for critical applications.
• Easy Maintenance: Faulty modules can be replaced online without process interruption.

4. Structure and Components

• Module Type: Digital Output (DO)
• Core Components:
  • Processor: TriCore PX720
  • Memory: 2 GB
  • Relays: High-quality relays for reliability
  • Optical Isolators: Isolate controller-load interference
  • Communication Interfaces: Modbus Plus, Profibus DP, Ethernet IP
  • Status Indicators: Run, fault, input/output status LEDs
  • Mounting: DIN rail
  • Connector: 37-pin D-sub
  • Housing Material: Aluminum alloy
  • Dimensions: 100mm x 50mm x 30mm or 124mm x 118mm x 30mm

————————————————————————————————————————–
