CONTROL TECHNIQUES 089EDC300BACAA Module
CONTROL TECHNIQUES 089EDC300BACAA
Product Overview
The CONTROL TECHNIQUES 089EDC300BACAA is a Unimotor HD industrial AC servo motor designed for precise motion control and high-speed operation. It features a compact 67 mm frame, a 460 V AC rating, and a maximum speed of 6000 RPM. With its incremental encoder and integrated holding brake, the motor supports applications that require accurate positioning, controlled movement, and reliable stopping performance.
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Type | AC Servo Motor |
| Series | Unimotor HD |
| Frame Size | 67 mm |
| Rated Voltage | 460 V AC |
| Frequency | 50/60 Hz |
| Maximum Speed | 6000 RPM |
| Continuous Stall Torque | 2.55 Nm |
| Feedback Device | 4096 PPR incremental encoder |
| Brake | Holding brake |
| Shaft Type | Keyed shaft with full key |
| Temperature Sensor | PTC thermistor |
Key Features
- High-Speed Performance: Supports rotational speeds of up to 6000 RPM for demanding motion-control tasks.
- Precise Feedback: The incremental encoder provides position and speed feedback to compatible servo drives.
- Integrated Holding Brake: Helps maintain the motor shaft position when the brake is correctly controlled.
- Compact Construction: The small frame size supports installation in space-constrained machinery.
- Thermal Monitoring: A PTC temperature sensor helps monitor motor temperature during operation.
Structure and Applications
The motor assembly includes a stator, rotor, shaft, bearings, encoder, electrical connectors, and a holding brake. These components work together to deliver controlled rotation and support accurate positioning.
Typical applications include automated packaging equipment, assembly machinery, material-handling systems, industrial robotics, and precision positioning equipment.
Installation and Maintenance
Mount the motor securely and ensure proper shaft alignment with the driven mechanism. Use a compatible servo drive, verify the power and feedback connections, and configure the encoder and brake according to the manufacturer’s instructions.
For routine maintenance, inspect connectors, cables, mounting hardware, and the shaft coupling. Also, monitor unusual vibration, overheating, and bearing noise. Always isolate the power supply before servicing the equipment.
Supply and Replacement Support
We supply industrial automation spare parts for maintenance, repair, and equipment replacement projects. Contact us to confirm stock availability, product condition, and compatibility with your existing servo system.
————————————————————————————————————-
