1. Overview

2. Specifications

• Measurement Range: 0-10000 PSI
• Accuracy: ±0.5% F.S. (Full Scale)
• Output Signal: 4-20mA Standard Analog Signal
• Power Supply Voltage: 12-36V DC (Supports Industrial Power Access)
• Connector Type: M8 Threaded Connection with Waterproof Sealing Design
• Temperature Range: -20℃ – +60℃
• Response Time: < 50ms

__________________________________________________________________________________________

3. Key Features

• High-Precision Reading: Equipped with a linear output design to ensure the linearity and accuracy of measurement results.
• Durable Design: The housing is made of high-strength engineering plastic, featuring corrosion resistance and impact resistance, suitable for harsh environments.
• Low-Power Operation: Complies with industrial energy-saving standards to ensure long-term stable operation of the equipment.
• Standardized Interface: The 4-20mA output is a universal standard in industrial automation systems, facilitating easy integration.

__________________________________________________________________________________________

4. Structure & Composition

• Sensor Body: The core component responsible for detecting physical quantities (such as pressure, temperature, etc.).
• Signal Conditioning Circuit: Converts the weak signal output by the sensor into a stable 4-20mA standard signal.
• Cables & Terminals: Adopts M8 specification with IP65 protection level to ensure the safety of electrical connections.

__________________________________________________________________________________________

5. Applications

• Automation Control Systems: Used to monitor machine operating status and feed back to PLC or DCS.
• Manufacturing Industry: Installed on production line equipment to monitor key process parameters in real time.
• Hydraulic Systems: Monitors pressure changes of hydraulic oil to ensure system safety.
• Environmental Monitoring: Some models can be used to monitor temperature and flow during industrial production processes.

__________________________________________________________________________________________

6. Installation & Maintenance

Installation Guidelines

• Connection: Use the M8 connector to fix the sensor on the target equipment (such as pressure vessels).
• Wiring: Connect the power terminal of the sensor to the power supply (12-36V DC), and connect the signal terminal to the analog input port of the control system.

Maintenance Points

• Regular Calibration: It is recommended to perform calibration every 6-12 months to ensure measurement accuracy.
• Cleaning and Maintenance: Regularly clean the sensor housing to avoid dust accumulation affecting heat dissipation.
• Protection Check: Inspect the connector sealing ring to ensure good waterproof performance.
