Allen-Bradley 1336-SN-SP10A Automation Processor Module
Allen-Bradley 1336-SN-SP10A
1. Overview
The Allen-Bradley 1336-SN-SP10A is an inverter snubber PCB board, belonging to the Level 2 Assembly component. It is a critical spare part for the 1336 series inverters, typically compatible with Frame E drives and designed for equipment with output power ranging from 150HP to 250HP (and X300HP).
________________________________________________________________________________________________________________________________
2. Specifications
|
Specification
|
Details
|
|---|---|
|
Applicable Series
|
1336 Plus, Plus II, Force, Impact
|
|
Compatible Frame
|
Frame E Drive
|
|
Voltage Rating
|
575V (AC)
|
|
Power Range
|
150 – 250 HP (X300HP supported)
|
|
Power
|
2400W (depending on specific configuration)
|
|
Output
|
8-channel relay output
|
|
Operating Temperature
|
0°C to 60°C (Industrial Standard)
|
|
Protection Class
|
IP67 (Waterproof and Dustproof)
|
|
Dimensions
|
140 mm x 85 mm x 25 mm
|
|
Weight
|
250 grams (approximately 0.90 pounds)
|
________________________________________________________________________________________________________________________________
3. Product Features
- Electromagnetic Interference (EMI) Suppression: As an inverter snubber, its main function is to suppress electromagnetic interference (EMI) and voltage spikes, protecting drives and motors from electrical noise.
- Modular Design: Adopts a modular design for easy and quick replacement and maintenance, reducing equipment downtime.
- High Reliability: Features a high protection class (IP67), enabling reliable operation in humid or dusty environments.
- Strong Compatibility: Custom-designed for the Allen-Bradley 1336 series, ensuring perfect matching with original factory drives.
________________________________________________________________________________________________________________________________
4. Structure and Composition
- Snubber PCB Main Board: The main circuit board responsible for filtering and suppressing electrical interference.
- Capacitor/Inductor Components: Used to absorb voltage spikes and limit current changes.
- Connection Terminals: For connecting signal lines between the drive and the motor..
________________________________________________________________________________________________________________________________
5. Application Fields
- Industrial Automation: Used in motor control systems of various automated production lines.
- Mechanical Equipment: Such as CNC machine tools, packaging machinery and other equipment requiring high-precision drives.
- Power and Energy: Applied in motor drive scenarios that require speed regulation.
- Conveyor Systems: Industrial conveyor equipment such as conveyor belts and elevators.
________________________________________________________________________________________________________________________________
6. Installation and Maintenance
Installation Location
Typically installed in the electrical cabinet between the inverter and the motor.
Installation Steps
- Power Off Operation: Before installation or replacement, the power must be cut off, and the Lockout/Tagout procedure must be followed.
- Remove Old Part: Dismantle the original snubber PCB.
- Install New Part: Install the 1336-SN-SP10A PCB in place and connect the corresponding cables and terminals.
- Inspection and Testing: Check if the wiring is secure and conduct a power-on test to verify the operation status of the inverter.
Maintenance Recommendations
- Regular Inspection: Check the appearance of the PCB for signs of burning, discoloration or corrosion.
- Environmental Requirements: Ensure the installation environment is dry, avoiding high temperature and humidity to prevent affecting its IP67 protection performance.
- Replacement Cycle: Depending on the equipment usage frequency and working environment, it is generally recommended to inspect it every 2-3 years as part of routine maintenance.
————————————————————————————————————-
