1. Product Overview

2. Technical Parameters

3. Product Features

• Modular Design: Adopts a modular structure to facilitate system integration and daily maintenance. The CPU module can be replaced independently while ensuring full compatibility with existing software, communication systems and I/O modules.
• ARCNET Communication: Supports the ARCNET communication protocol to realize efficient and stable communication with controllers, making it ideal for distributed control systems.
• Dual Serial Port Configuration: Built-in two Modbus interfaces (RS232/485) allow direct connection with on-site field devices for convenient data interaction.
• Powerful Expansion Capability: In addition to native built-in communication functions, it supports the expansion of up to 4 additional communication modules, compatible with multiple bus protocols including Profibus DP, DeviceNet and CANopen.
• Memory Card Support: Equipped with an SD card interface for convenient program backup, data storage and data transmission.
• User-Friendly Operation: Integrated with an LCD display and physical operation keys, enabling convenient on-site equipment debugging, real-time monitoring and parameter adjustment.
• High Compatibility: Shares the same programming software with other AC500 series CPU modules (PM571, PM581, PM582, PM590, PM591, etc.) and supports six standard IEC61131-3 programming languages.

4. Structure and Composition

• CPU Module: PM590-ARCNET serves as the core control unit of the entire system to undertake logic operation, data processing and system control tasks.
• Base Module: Available in three types with 1, 2 or 4 expansion slots respectively to meet different system expansion demands.
• I/O Modules: Include analog input/output (AI/AO) modules and digital input/output (DI/DO) modules for signal collection and output control.
• Communication Modules: Optional pluggable bus interface modules for expanding diversified communication functions.
• Power Supply Module: 24VDC power supply unit to provide stable power for the system.
• Accessories: Supporting accessories such as wiring terminals and mounting brackets.

5. Application Fields

• Industrial automation systems: Automatic control for process industry and discrete manufacturing industry
• Process control: Real-time process monitoring and control for chemical, petroleum, natural gas and other process industries
• Mechanical equipment control: Sequential control of various production machinery and assembly equipment
• Distributed control systems: Distributed network applications requiring multi-node data communication
• SCADA systems: Industrial data acquisition, remote monitoring and control systems
• Building automation: Intelligent monitoring and operational management of smart building equipment
• Transportation systems: Signal control and system regulation for rail transit such as subways and railways

6. Installation and Maintenance

6.1 Installation Requirements

6.1.1 Environmental Conditions

• Ambient Temperature: 0-55°C (standard operating range); -40-70°C (extended temperature range)
• Humidity: 5%-95% (non-condensing)
• Installation environment: Keep away from strong electromagnetic interference, corrosive gas and heavy dust environments to ensure stable operation

6.1.2 Installation Steps

1. Fix the PLC base on the control cabinet or standard installation guide rail firmly.
2. Vertically insert the PM590-ARCNET CPU module into the base slot in place.
3. Fasten the module with fixing screws to avoid loosening caused by vibration.
4. Complete the connection of power supply lines, communication cables and I/O wiring as required.

6.1.3 Wiring Specifications

• Power Wiring: Correctly connect the positive and negative poles of the 24VDC power supply to avoid reverse connection damage.
• ARCNET Network Wiring: Adopt a standard bus topology for network layout.
• Serial Interface Wiring: Follow industry standard specifications for RS232/485 interface wiring to ensure normal data communication.
