1. Product Overview

2. Main Parameters and Specifications

• Test Force Capacity: 50kN (approximately 5000kgf), meeting the testing needs of high-strength cables.
• Speed Range: 0.01 – 250 mm/min (adjustable).
• Test Stroke: 800mm (adjustable).
• Load Resolution: 1/500000, accuracy class 0.5.
• Measurement Range: Effective measurement range 0.4% – 100%, displacement resolution 0.001mm.
• Standard Compliance: Complies with international and domestic standards such as GB/T 33594, CQC 1103, IEC60227-2, IEC60245-2.

______________________________________________________________________________________________________________

3. Product Features

• High Precision and Stability: Adopts a microcomputer control system, which can accurately set the test force and duration, and clearly display the relationship curve between force value and displacement.
• Safety and Reliability: Equipped with overload protection function (when rated power ≥ 4kW), complying with the requirements of electrical safety technical specifications.
• Strong Adaptability: Supports extrusion resistance tests of different specifications of flexible cables (such as aluminum alloy round-bottom pulleys required in CQC1103 standard).

______________________________________________________________________________________________________________

4. Structure and Composition

• Host Frame: Usually adopts steel structure or cast iron frame to ensure the stability of the equipment under high load.
• Hydraulic/Mechanical Transmission System: Provides constant pressure or force value. The core components may include oil cylinders (if it is a hydraulic system) or high-precision lead screws (if it is a mechanical system).
• Microcomputer Control Panel: Includes display screen, keyboard and data interface for parameter setting, process monitoring and data recording.
• Support Device: Includes fixed fixtures, pressure plates and measuring sensors (such as strain gauges or pressure sensors) for supporting and measuring the test sample.
• Power Supply and Protection System: Equipped with overload protection device and emergency stop switch to ensure safe operation.

______________________________________________________________________________________________________________

5. Application Fields

• Power Cable Manufacturing: Used to detect the extrusion resistance of cable sheaths, ensuring their damage resistance during laying.
• Wire and Cable Testing: Used for laboratory testing and quality control to evaluate the mechanical properties of cables in extreme environments.
• R&D and Testing: Used by wire and cable R&D departments for material performance analysis and new product verification.

______________________________________________________________________________________________________________

6. Installation and Maintenance

Installation Points

• Environmental Requirements: Should be installed in a dry and well-ventilated environment to avoid dust and corrosive gas erosion. It has certain requirements on temperature and humidity (such as operating in -30°C – +55°C environment).
• Power Supply Requirements: Ensure that the power supply voltage is consistent with the rated voltage of the equipment, and that it is equipped with grounding protection.

Maintenance

• Daily Maintenance: Keep the equipment clean, regularly check the oil level and oil quality of hydraulic oil (if applicable); check the connection status of sensors and electrical lines.
• Calibration: Perform regular calibration to ensure the accuracy of measurement data such as force value and displacement. Professional calibration is recommended every six months to one year.
• Lubrication: For mechanical transmission parts (such as lead screws), regularly add lubricating oil to prevent wear.
