ABB 600PSM03 600-PSM03 1KHL300014 1KHL178016R0001G Power Module
ABB 600PSM03 600-PSM03 1KHL300014 1KHL178016R0001G
1. Product Overview
2. Technical Parameters
|
Parameter Item
|
Specification
|
|---|---|
|
Input Voltage
|
24 V DC to 60 V DC (Tolerance: -20% / +15%)
|
|
Output Voltage
|
5 V DC and 24 V DC
|
|
Output Power
|
Maximum 30 Watts
|
|
Efficiency
|
More than 80%
|
|
Dimensions
|
160 mm x 100 mm (Standard 3U European Card Format)
|
|
Weight
|
Approx. 0.25 kg
|
|
Operating Temperature
|
-25°C to +70°C
|
|
Origin
|
Germany / Switzerland (Subject to production batches)
|
|
Version
|
Rev. E
|
Input Voltage Protection Features
- The module will automatically shut down to protect downstream equipment when the input voltage is lower than 19V.
- The maximum power-off duration can reach 50 milliseconds without equipment re-initialization.
- An external Miniature Circuit Breaker (MCB) must be equipped at the power input terminal for protection.
3. Product Features
- High Reliability: Designed exclusively for industrial environments with extremely high equipment availability.
- Strong Anti-interference Capability: Equipped with superior EMI resistance, suitable for complex electrical environments.
- Wide Temperature Design: Operating temperature range from -25°C to +70°C, adaptable to various harsh working conditions.
- Standardized Interface: Adopts standard 3U European card format for easy installation and replacement.
- Dual Output Voltage: Provides both 5V and 24V DC outputs to meet diverse load requirements.
- Low Power Consumption & High Efficiency: Supports a maximum load of 35W with a power conversion efficiency exceeding 80%.
- Intelligent Protection: Built-in undervoltage automatic shutdown protection function.
4. Structure and Composition
Physical Structure
- Installation Format: Standard 3U European card (DIN rail mounting or backplane slot mounting)
- Interface Type: Standard power input and output connectors
- Fixing Method: Front panel fixing screws + backplane connectors
Typical Module Components
- Input Filter Circuit (EMI Filter)
- DC-DC Conversion Module
- Output Voltage Stabilization Circuit
- Overvoltage / Overcurrent Protection Unit
- LED Status Indicator
- Heat Sink / Metal Shell (Enhanced Heat Dissipation)
LED Status Indication
- Power Indicator: Lights up during normal operation.
- Fault Alarm Indicator: Triggers when abnormal operating conditions occur.
5. Application Fields
5.1 Power Grid Automation
- Substation automation systems
- Power supply for RTUs used in circuit breaker and transformer monitoring
- Power monitoring systems
5.2 Renewable Energy
- Wind farm control systems
- Monitoring equipment for solar power plants
- Distributed energy management systems
5.3 Oil and Gas Industry
- Pipeline and wellhead controller monitoring
- Supervisory Control and Data Acquisition (SCADA) systems
- Remote industrial control equipment
5.4 Smart Grid
- Distribution network automation equipment
- Smart meter management systems
- Distributed energy access control
5.5 Industrial Control
- Remote Terminal Units (RTU)
- Process control systems
- Industrial automation rack systems
