Lam Research 810-001489-132 Valve Control PCB

Short Description:

The Lam Research 810-001489-132 is a specialized electronic part number associated with Lam Research semiconductor manufacturing equipment. Publicly available spare-parts references show that the 810-001489 family is used for valve-control electronics, including the 810-001489-002 Dual Valve Control Board Assembly and the 810-001489-015 Rocker Valve Interface Control Board.

FOB Price: US $0.5 - 9,999 / Piece

Min.Order Quantity: 100 Piece/Pieces

Supply Ability: 10000 Piece/Pieces per Month

Brand: Lam Research

Manager: Jinny

E-mail: sales5@xrjdcs.com

Tel: + 86-18250705533

( WhatsApp )Wechat: + 86-18250705533

Warranty: one year

In stock: In stock

Send email to us Download as PDF

Product Detail

Product Tags

Lam Research 810-001489-132

Product Overview

Because detailed manufacturer documentation for the exact -132 revision is limited in public sources, it is best treated as an equipment-specific control PCB rather than assuming specifications from another revision. For replacement purposes, the complete part number and revision should be matched carefully.

Part Details

The main identification information is listed as follows:

Manufacturer: Lam Research
Part Number: 810-001489-132
Product Category: Industrial control PCB
Related Part Family: 810-001489 series
Typical Function: Valve and equipment control
Industry: Semiconductor manufacturing
Installation: Lam Research equipment-specific
Typical Use: Replacement, repair and spare-parts inventory

The related 810-001489-002 is specifically listed as a Dual Valve Control Board Assembly, while 810-001489-015 is identified as a Rocker Valve Interface Control Board.

Functional Characteristics

Control boards in this family are designed to form part of the machine-level electronic architecture used to manage equipment functions. Valve-control electronics can provide the interface between control logic and pneumatic or vacuum-related components, helping coordinate machine operations.

Potential characteristics of the 810-001489-132 include:

Specialized semiconductor-equipment control circuitry
Integration with machine valve-control systems
Compact PCB-based construction
Designed for equipment-specific installation
Suitable for maintenance and replacement applications
Useful for supporting legacy Lam Research equipment

The exact I/O configuration, electrical ratings and valve channels should be verified from the original board and equipment documentation before installation.

Construction and System Integration

The board is expected to incorporate a printed circuit board, electronic control components, connectors and interface circuitry. It operates as one element within a larger Lam Research automation system rather than as an independent controller.

Depending on the host equipment, associated hardware may include valve assemblies, pneumatic components, sensors, interlock circuits, communication interfaces and higher-level control electronics.

This makes revision matching especially important. Lam Research’s available parts listings show multiple revisions within the 810-001489 family, including different versions of the Dual Valve Control Board. A replacement should therefore not be selected solely because the basic 810-001489 prefix is similar.

Semiconductor Manufacturing Applications

The 810-001489 series is relevant to semiconductor equipment where accurate control of machine valves and associated process hardware is required. Such control functions can be important in equipment involving vacuum, gas handling, pneumatic actuation and automated process sequences.

Typical maintenance applications may include:

Semiconductor wafer-processing equipment
Valve-control systems
Vacuum and gas-handling equipment
Lam Research equipment refurbishment
PCB replacement
Preventive maintenance
Legacy equipment support
Critical spare-parts inventory

Having a suitable replacement board available can help reduce troubleshooting and equipment recovery time when an existing control PCB fails.

Installation and Maintenance

Before installation, technicians should compare the complete 810-001489-132 identification with the original component. Check the board revision, connector arrangement, mounting points and associated equipment part numbers.

Use appropriate ESD protection when handling the PCB. Power should be isolated according to the applicable equipment maintenance procedure before removing the original board.

After installation, carefully inspect all connectors and wiring. Restore power only after confirming that the assembly has been installed correctly. The host equipment should then undergo its normal initialization, diagnostic and functional checks.

For storage, keep the board in anti-static packaging in a clean, dry environment. Avoid unnecessary exposure to moisture, dust and mechanical shock.

Replacement and Supply Support

The Lam Research 810-001489-132 is a specialized semiconductor-equipment spare part, and accurate identification is important because the broader 810-001489 family contains multiple control-board configurations and revisions.

We supply industrial automation and semiconductor equipment spare parts and can assist customers with sourcing difficult-to-find Lam Research components. When requesting this model, providing a clear photograph of the original label, PCB revision and connector side is recommended so the required configuration can be checked before shipment.
