Abb 560CMU80R1 1KGT008800R0001 Communication Module

Short Description:

The ABB 560CMU80R1 1KGT008800R0001 is a central control communication module belonging to the ABB RTU560 series, which is part of the industrial automation Remote Terminal Unit (RTU) product family

FOB Price: US $0.5 - 9,999 / Piece

Min.Order Quantity: 100 Piece/Pieces

Supply Ability: 10000 Piece/Pieces per Month

Brand: ABB

Manager: Jinny

E-mail: sales5@xrjdcs.com

Tel: + 86-15359273791

( WhatsApp )Wechat: + 86-15359273791

Warranty: one year

In stock: In stock

Send email to us Download as PDF

Product Detail

Product Tags

Abb 560CMU80R1 1KGT008800R0001

1. Product Overview

The ABB 560CMU80R1 1KGT008800R0001 is a central control communication module belonging to the ABB RTU560 series, which is part of the industrial automation Remote Terminal Unit (RTU) product family.

As a core component of the RTU560 system, this module is mainly responsible for I/O module management, process event reading, command transmission and multi-system intercommunication. It plays a vital role in industrial automation, remote monitoring and Supervisory Control And Data Acquisition (SCADA) systems.

2. Main Technical Specifications

Parameter Item	Specification
Processor	32-bit ARM Cortex-A8 Controller (AM3352)
Main Frequency	≥200 MHz
Memory	128 MB RAM, 256 MB Flash
Serial Interface	2 × RS-232/RS-485 ports
Ethernet Interface	2 × 10/100BaseT (RJ45) ports
USB Interface	1 × USB port
Real-Time Clock	Battery-backed
Power Supply Voltage	24V DC or 48V DC (configurable)
Power Consumption	Typical: 5W – 15W
Operating Ambient Temperature	-25°C to +70°C
Ingress Protection Rating	IP20 (for indoor cabinet installation)

3. Product Features

3.1 High-Performance Processing

Equipped with a high-performance 32-bit RISC CPU, the module supports massive real-time data processing and can execute complex logic operations and industrial control tasks stably and efficiently.

3.2 Multi-Protocol Compatibility

It supports mainstream industrial communication protocols including IEC 60870-5-101/104, DNP3, Modbus, PROFIBUS and OPC, ensuring excellent compatibility with diverse industrial devices and systems.

3.3 High-Reliability Design

It adopts a three-level redundancy design covering power supply, communication lines and CPU, effectively avoiding system downtime caused by single-point faults. The built-in ProConOS real-time operating system guarantees outstanding processing performance and long-term operational stability.

3.4 Flexible Scalability

Featuring hot-swap capability and modular design, the module enables convenient system expansion, equipment replacement and daily maintenance without interrupting the normal operation of the entire system.

3.5 International Standard Compliance

The product has obtained CE, UL and other international certifications, and complies with the IEC 61131-3 PLC logic standard, meeting global industrial safety and performance specifications.

4. Structure and Composition

4.1 Physical Specifications

Dimensions: Approximately 140×203×58mm (19-inch 3HE Euro card format)
Weight: Approximately 0.21kg
Installation Method: Rack mounting / DIN rail mounting

4.2 System Architecture

The RTU560 system adopts a multi-processor distributed architecture, with the core components as follows:

Central Control Module (CMU): 560CMU80R1 serves as the core control unit of the entire system
I/O Module: Supports extended analog input/output and digital input/output functions
Power Supply Module: 560PSU01/02, supports redundant power supply configuration to improve system reliability
Communication Expansion Module: Including 560CMR01/02 and other extended models

4.3 Communication Structure

The CMU communication unit is configured with diversified interfaces to meet multi-scenario communication demands:

2 × Serial interfaces (RS-232/RS-485) for long-distance remote communication
2 × Ethernet interfaces (10/100BaseT) for high-speed network transmission
1 × USB interface for local debugging and data upload/download
1 × SPI bus interface for internal system data interaction

5. Application Fields

With superior performance and strong compatibility, this module is widely applied in industrial monitoring and control scenarios across multiple industries:

5.1 Power System

Substation Automation System (SAS), power dispatching control, power transmission and distribution monitoring

5.2 Industrial Automation

Industrial process control, Supervisory Control and Data Acquisition (SCADA) system, production line automatic integration

5.3 Energy Management

Oil and gas pipeline network monitoring, wind power, hydropower and nuclear power station monitoring, renewable energy power station operation control

5.4 Smart City & Infrastructure

Water conservancy telemetry and monitoring, urban public infrastructure monitoring system

————————————————————————————————————-
