Abb 768417 Circuit Breaker
Abb 768417
Product Features
- High Breaking Capacity: The rated short-circuit breaking capacity reaches up to 36kA (Type N) and 50kA (Type S).
- Dual Arcing Contact Structure: Effectively limits the passing energy and peak current under short-circuit conditions.
- Wide Voltage Range: Supports rated operating voltages of 400/690V AC and 250/750V DC.
- Flexible Rated Current: Covers a current range of 0.5A to 63A, with a maximum rated current of 125A.
- Compact Design: Featuring a miniaturized size, it is ideal for installation in space-constrained scenarios such as wind power generation systems.
- Environmental Certification: Compliant with the ISO 14001 environmental management system standard.
Technical Parameters
|
Parameter Item
|
Specification Value
|
|---|---|
|
Rated Operating Voltage
|
230/400V AC (maximum 1150V AC)
|
|
Rated Current
|
0.5A – 125A
|
|
Short-circuit Breaking Capacity
|
36kA (Type N) / 50kA (Type S)
|
|
Operating Temperature Range
|
-25°C to +60°C
|
|
Ingress Protection Rating
|
IP40
|
|
Maximum Operating Current
|
63A
|
|
Mechanical Shock Resistance
|
IK08
|
|
Flame Retardant Rating
|
650°C/850°C
|
Structure & Composition
- Circuit Breaker Main Body: Equipped with a professional dual arcing contact structure and high-precision tripping device to realize reliable short-circuit and overload protection.
- Wiring Terminals: Standardized terminal design for stable and safe electrical connection.
- Installation Accessories: Complete DIN rail mounting fittings for quick and fixed installation.
- Protection Modules: Optional extended modules including motor protection and residual current leakage protection to meet diverse application needs.
Application Fields
- Wind Power Generation: Special low-voltage protection solution for wind power equipment systems.
- Data Centers: Applied to the protection of rack PDU power distribution units to ensure stable power supply for server equipment.
- Industrial Power Distribution: Suitable for various types of low-voltage power distribution systems in industrial production sites.
- Commercial Buildings: Provides reliable electrical safety protection for building power supply systems.
- Other Industrial Fields: Widely applicable to steel, textile, papermaking and other traditional industrial manufacturing industries.
Installation & Maintenance
Installation Requirements
- Operating and installation temperature: -25°C to +60°C
- Protection grade: IP40
- Installation method: DIN rail snap-on installation, fast and convenient
- Cable entry: Knockout type cable entry design
Maintenance Suggestions
- Regularly check the tightness of wiring terminals to avoid poor contact caused by loose connections.
- Inspect the equipment shell regularly to confirm that the IP40 protection performance is not damaged.
- Carry out performance tests in accordance with the manufacturer’s official recommended cycle to ensure protective performance.
- Ensure that the ambient temperature and humidity of the installation site are within the allowable operating range of the equipment.
