ABB CP555 1SBP260179R1001 Control Panel
ABB CP555 1SBP260179R1001
1. Product Overview
Basic Product Information
- Product ID: 1SBP260179R1001
- Model: CP555
- Product Type: PLC-CP500 Control Panel
- Supporting Software: CP500soft
2. Technical Parameters
|
Parameter Item
|
Specification
|
|---|---|
|
Screen Size
|
10.4 Inches
|
|
Screen Type
|
TFT Touch Display Screen
|
|
Display Resolution
|
640 × 480 Pixels
|
|
Display Colors
|
256 Colors
|
|
Overall Dimensions
|
290 mm (W) × 250 mm (H) × 114 mm (D)
|
|
Net Depth
|
105 mm
|
|
Net Weight
|
3 kg
|
|
Gross Weight
|
3.1 kg
|
|
Input Voltage
|
24 V DC
|
|
Memory Capacity
|
1600 kB (User Data) / 1600 kB (User Program)
|
|
Storage Type
|
1600 kB Non-volatile RAM / 1600 kB Flash EPROM
|
|
Fuse Specification
|
F6.3A
|
|
Service Life
|
50,000 Hours
|
|
Ingress Protection Rating
|
IP65
|
3. Product Features
- High-Performance Display: Equipped with a 10.4-inch TFT touch screen, it supports 256-color display, presenting clear graphical and text display effects for industrial scenarios.
- User Security Protection: Adopts an 8-level user password protection mechanism to effectively prevent unauthorized operation and ensure system operation safety.
- Real-Time Clock: Built-in real-time clock module supports accurate event logging and real-time data processing for industrial control systems.
- Rich Communication Interfaces: Supports multiple industrial communication protocols and modes, including Modbus RTU/AC500, Modbus ASCII, optional Profibus DP Slave, Modbus TCP/IP, and serial ports compatible with PR, MODBUS, ASCII and other mainstream protocols.
- Standard Industrial Protection: Features IP65 ingress protection rating, which is dust-proof and water-resistant, adapting to harsh industrial operating environments.
- Professional Software Support: Matched with CP500 Soft programming software, it simplifies system configuration, screen design and program editing for efficient project development.
- Authoritative Compliance Certifications: Certified with CUL and CE certifications, meeting international industrial safety and quality standards.
4. Structure and Composition
4.1 Installation Structure
- Installation Method: Front panel mounting
- Unsupported Installation: DIN rail mounting is not applicable
4.2 Main Components
- TFT Touch Display Screen
- Control Processing Unit
- Communication Interface Module
- Power Input Module
- Non-volatile Memory
4.3 File Support
- GSD File: CP500_IFC-PBDP.gsd (for PROFIBUS communication configuration)
4.4 Packaging Information
- Packaging Type: Standard carton packaging
5. Application Fields
- Industrial Control System: Serves as a dedicated operator interface for PLC control systems
- Process Control: Applied to monitoring and control of industrial automated production lines
- Equipment Management: Used as an operation panel for factory mechanical and electrical equipment
- Data Acquisition: Acts as a terminal for industrial data collection, display and query
- System Integration: Compatible with mainstream industrial bus systems such as Modbus and Profibus for seamless system integration
- General Automation Scenarios: Suitable for all industrial scenarios requiring graphical human-computer interaction functions
6. Installation Guide
6.1 Pre-installation Preparation
- Confirm that the selected installation position complies with relevant electrical safety specifications
- Verify that the opening size of the installation panel meets the product requirements
- Prepare professional installation tools and matching fasteners
6.2 Installation Steps
- Drill and reserve a mounting hole of standard size on the front panel
- Insert the CP555 device into the mounting position from the front of the panel
- Fix and lock the device with matching fixing clips or fasteners
6.3 Wiring Requirements
- Access standard 24 V DC power input for stable power supply
- Connect corresponding communication cables according to actual communication protocol requirements
- Ensure reliable grounding to avoid electromagnetic interference affecting device operation
6.4 Environmental Requirements
- Operating Temperature: Refer to the official product manual (1SBC159002M0202) for detailed parameters
- Avoid operating in humid environments and environments with corrosive gases
- Maintain good ventilation and heat dissipation conditions around the device
