ABB RXNAC-2H-RK-862-005-BB Protective Relay
ABB RXNAC-2H-RK-862-005-BB
Overview
Technical Parameters
|
Parameter Type
|
Reference Value
|
|---|---|
|
Operating Temperature
|
—
|
|
Storage Temperature
|
—
|
|
Rated Voltage
|
12-48VDC or 120VAC (Refer to RXIDK 2H Series)
|
|
Rated Current
|
10A (Refer to RXIDK 2H Series)
|
|
Frequency
|
50/60Hz
|
|
Output Contact
|
2 Change-over Contacts (C/O)
|
|
Dimension
|
Modular design, compatible with Combiflex rack mounting
|
Product Features
- High Performance & Reliability: Engineered for harsh industrial environments with stable and dependable operation performance.
- Modular Design: Simplifies on-site installation, routine maintenance and subsequent system expansion.
- Redundant Architecture: Products with the suffix “2H” adopt dual-processor redundant architecture, supporting millisecond-level fault switching.
- High Availability: Versions marked with “HA” support operation under wide-temperature ambient conditions.
- LED Indicator Lights: Real-time status indication for service, startup, tripping and other working states.
- High Reset Ratio: The reset ratio is higher than 97%.
Structure & Composition
- Modular Structure: Standardized structure for installation on Combiflex racks.
- Auxiliary Power Supply: Partial models require an external DC/DC converter (e.g. RXTUG module).
- LED Status Indication: Visual status display for service, startup, tripping and other operating modes.
- Wiring Terminals: Equipped with screw terminals or spring terminals for field wiring connection.
Application Fields
|
Industry
|
Application Description
|
|---|---|
|
Power Industry
|
Power energy supply and substation protection
|
|
Petrochemical Industry
|
Process control and safety instrumented system operation
|
|
Data Center
|
Busbar protection, fault clearing time < 40ms
|
|
Manufacturing Industry
|
Industrial automation and PLC control system matching
|
|
Water Treatment Industry
|
Process monitoring and automated operation control
|
|
Metallurgy, Pharmaceutical, Food & Beverage Industry
|
General industrial process automatic control
|
Installation & Maintenance
Installation Requirements
- Mounting Method: Rack-mounted installation supported by modular structural design
- Ambient Requirements: Comply with specified operating temperature range
- System Compatibility: Compatible with other functional modules of ABB 800xA system
- Fixing Standard: Applicable to EN/IEC 60715 or DIN 35 standard guide rail installation
Maintenance Recommendations
- Check the working state of LED indicator lights regularly
- Keep on-site ambient temperature and humidity within the rated specification range
- Tighten wiring terminals periodically to avoid loose connection faults
- Carry out standardized preventive maintenance per the official ABB maintenance manual
————————————————————————————————————-
