ABB TU848 redundant configuration

Short Description:

The ABB TU848 is part of the ABB S800 I/O system, specifically designed for redundant configurations. It is used to connect the TB840/TB840A optical module bus. By providing dual ModuleBus and dual power supply connections, it ensures the system can operate normally in the event of a single-point failure.

FOB Price: US $0.5 - 9,999 / Piece

Min.Order Quantity: 100 Piece/Pieces

Supply Ability: 10000 Piece/Pieces per Month

Brand: ABB

Manager: Jinny

E-mail: sales5@xrjdcs.com

Tel: + 86-15359273791

( WhatsApp )Wechat: + 86-15359273791

Warranty: one year

In stock: In stock

Send email to us Download as PDF

Product Detail

Product Tags

ABB TU848

This module is suitable for industrial automation applications requiring high reliability and safety, such as the power, motion control, and wind turbine industries.

Parameters

Model: TU848
Brand: ABB
Origin: Switzerland
Voltage input: 24 V DC (19.2-30 V)
Dimensions: 124 mm (4.88 inches) in width, 47 mm (1.85 inches) in depth, 186.5 mm (7.34 inches) in height; weight: 500 grams (1.1 pounds)
Protection class: IP20
Certification: CE certification
Installation method: Vertical or horizontal installation
Function: Supports cable redundancy and module redundancy

Main Features

Dual ModuleBus connections: Supports dual ModuleBus configurations for TB840/TB840A, enhancing system redundancy.
Dual power supply connections: Provides two independent power inputs to ensure the system operates normally in case of a single-point failure.
Mechanical key locking: Prevents insertion of incorrect modules, improving system safety.
Rotary switch settings: Used to set cluster addresses, facilitating system configuration and management.
DIN rail mounting: Supports standard DIN rail installation for easy installation and maintenance.

Structure and Composition

The ABB TU848 consists of the following parts:

Two TB840 chips: Marked as X6A and X6B respectively, they are used for data transmission and clock synchronization.
Power connections: Including +24V_A, +24V_B, +5V_A, +5V_B, and 0V, which supply power to the module.
Signal connections: Including POWOK_A, POWOK_B, DAT_A, DAT_B, CLK_A, and CLK_B, used for data transmission and clock synchronization.
External connections: Including X1A, X1B, X3A, and X3B, which are used to connect external devices.
CLUSTER component: May be used for data processing or control.

Main Application Fields

The ABB TU848 is mainly applied in the field of industrial automation, especially in systems requiring high reliability and safety. It is used with the AC 800M central processing unit and widely applied in the power, motion control, and wind turbine industries. In addition, it is suitable for industrial control systems requiring redundant configurations, such as factory automation, process control, and energy management.

Installation and Maintenance

Installation: The ABB TU848 can be installed vertically or horizontally on a standard DIN rail, facilitating installation and maintenance. During installation, ensure correct power and signal connections, and use mechanical key locking to prevent insertion of incorrect modules.
Maintenance: ABB provides intelligent diagnosis and maintenance functions, as well as maintenance tools and support services to ensure the normal operation of the system. Regularly check power and signal connections to ensure stable system operation.

———————————————————————————————————————————
