ABB YPK112A Module Card
ABB YPK112A
The ABB YPK112A is a module card designed for industrial automation systems, belonging to the ABB system card series. Featuring a plug-and-play design, it is compatible with a wide range of ABB electrical devices (including relays, contactors, and circuit breakers), enabling quick integration into control systems. Positioned as a universal, high-reliability fieldbus/fieldbus gateway module, it is ideal for applications in power plants, substations, industrial production lines, and rail transit systems.
Key Technical Specifications
- Processor: 32-bit RISC with a clock speed of approximately 100 MHz
- Memory: 128 MB RAM, 256 MB Flash
- Communication Interfaces: Supports multiple fieldbus protocols including CANopen, Modbus, RS-232/485, and Ethernet
- Operating Voltage: Standard 24 V DC or 120 V AC
- Operating Temperature: -25 °C to +60 °C (industrial-grade)
- Protection Class: IP65, providing dustproof and waterproof performance
- Dimensions: Approximately 100 mm × 80 mm × 30 mm (suitable for cabinet installation)
Product Features
- High Versatility: Compatible with various ABB electrical components to meet the wiring requirements of different projects.
- Easy Installation: Adopts a plug-in card structure that allows quick assembly without special tools.
- Superior Reliability: Made of high-quality materials with anti-interference and anti-vibration properties, suitable for harsh industrial environments.
- Comprehensive Safety Protection: Built-in multiple protection functions such as overload, short-circuit, and undervoltage protection to ensure safe system operation.
- Multi-Protocol Compatibility: Supports common fieldbuses like CANopen, Modbus, RS-485, and Ethernet, facilitating seamless data exchange with upper-level systems or PLCs.
Structure and Components
- Main Control Board: Equipped with a 32-bit RISC processor, responsible for data processing and protocol conversion.
- Communication Interface Module: Provides physical interfaces for CAN, Modbus, RS-485, and Ethernet.
- Power Supply Module: Accepts 24 V DC/120 V AC input and supplies stable voltage to all sub-modules internally.
- Protective Housing: IP65-rated metal casing with shielded internal wiring design.
- Terminal Block: Used for connecting power and signal lines of field devices with clear markings.
Typical Application Areas
- Power Systems: Generator excitation control, substation automation, distribution automation.
- Industrial Automation: Production line control, robot systems, process control.
- Rail Transit: Train power supply systems, signal control modules.
- Energy and Environmental Protection: Wind power, photovoltaic inverter monitoring, sewage treatment automation.
Installation and Maintenance Guidelines
- Pre-installation Inspection: Verify that the power voltage and interface type match the field devices; check the card for any physical damage.
- Mechanical Assembly: Insert the card into a standard DIN rail or cabinet slot and ensure it is securely fastened without loosening.
- Electrical Wiring: Connect power and signal lines to the corresponding terminals according to the wiring diagram, paying attention to polarity and preventing misconnection.
- Communication Configuration: Use ABB configuration software (e.g., Automation Builder) to set communication protocol parameters (baud rate, node address, etc.).
- Function Testing: Perform a self-test after power-on and check the indicator status; read the module status via the upper computer to confirm normal data interaction.
————————————————————————————————————-
