Schneider AEG 120-166-006

AEG 120-166-006 is a brushless motor belonging to the Modicon series of Schneider Electric (formerly AEG Schneider Automation). It is widely used for driving and positioning in industrial automation, PLC control cabinets and field I/O modules.

Key Technical Specifications

Product Features

1. Brushless Structure: Eliminates brush wear, featuring long service life and low maintenance cost.
2. High Efficiency: High electrical energy conversion efficiency and low running noise, ideal for noise-sensitive work sites.
3. Modular Design: Equipped with plug-in terminals for quick assembly, expansion and replacement.
4. Multiple Protections: Built-in overload, overvoltage and short-circuit protection, compliant with industrial safety standards.
5. Strong Compatibility: Directly compatible with Modicon PLC, I/O modules and other Schneider Electric automation products.

Structure & Components

• Motor Body: Brushless rotor, stator winding and permanent magnet
• Drive Unit: Integrated power electronics (IGBT/MOSFET) for brushless commutation
• Terminals: Standard M12/M23 interfaces supporting fast on-site wiring
• Protective Housing: Metal casing with IP65 protection, adaptable to harsh industrial environments
• Mounting Accessories: Brackets, bolts, grounding terminals, etc., for easy fixation on cabinets or panels

Typical Application Fields

• Industrial Automation: Production line driving, conveyor belts, packaging machinery
• Process Control: Valve or pump driving in continuous processes such as chemical industry, metallurgy and water treatment
• Building Facilities: Fan driving for air conditioning and ventilation systems
• Energy Stations: Auxiliary motors inside power distribution cabinets and distribution boxes
• PLC & I/O Module Power Supply: Providing reliable power for Schneider Modicon series controllers

Installation & Maintenance Essentials

1. On-site Inspection: Confirm that the power voltage and frequency match the motor’s rated parameters; check heat dissipation and ventilation inside the cabinet.
2. Mechanical Fixation: Use the supplied brackets and bolts to firmly mount the motor on cabinets or panels, ensuring the protective housing is fully sealed.
3. Electrical Wiring: Adopt standard M12/M23 interfaces, connect power supply, control signals and grounding according to the wiring diagram, and avoid cross wiring.
4. Commissioning: After power-on, check if the motor rotation direction and speed meet specifications; use diagnostic software provided by Schneider to read fault codes.
5. Regular Inspection: Check terminal tightness, housing integrity and dust accumulation on heat sinks every 6-12 months; the brushless motor itself requires no brush replacement.
