Schneider AEG MM-P10-200 Power Distribution Module
Schneider AEG MM-P10-200
The MM-P10-200 is one of the modular low-voltage distribution product lines launched by Schneider Electric after its acquisition of Germany’s AEG, belonging to the MM (Modular-Mount) series. Adhering to the core design philosophy of modularization, stackability and flexible combination, this series is suitable for various scenarios including industrial power distribution, building equipment rooms, energy stations and rail transit. Specifically, MM-P10-200 refers to a distribution module with a width of 10 cm (100 mm) and a rated voltage of 200 V (commonly 200 V DC or 200 V AC).
1. Key Technical Parameters
| Item | Typical Value |
|---|---|
| Rated Voltage | 200 V AC / 200 V DC (optional) |
| Rated Current | 63 A, 125 A, 250 A (optional) |
| Short-time Withstand Current | 10 kA, 15 kA, 25 kA (optional) |
| Rated Power | ≤ 45 kW (depending on selected module combination) |
| Operating Temperature Range | -25 °C – +55 °C |
| Protection Grade | IP20 (internal) / IP54 (enclosure) |
| Installation Method | Wall-mounted, frame-mounted, base-fixed (bolted or welded) |
| Module Dimensions | Width 300 mm, depth 400 mm, height 200 mm – 800 mm (stackable) |
2. Product Features
- Modular Stacking: Different functional modules (circuit breakers, contactors, relays, measurement & protection devices, PLC, communication modules, etc.) can be freely stacked in the same cabinet to achieve integrated power distribution.
- Flexible Combination: Each functional module adopts a unified specification of 300 mm × 400 mm, allowing users to add or reduce modules at any time according to load requirements.
- High Reliability: Equipped with copper/aluminum busbars fixed by elastic buckles for quick assembly and disassembly; the short-time withstand current reaches up to 25 kA, meeting the inrush current demands of industrial sites.
- Intelligence: Some modules are built-in with digital communication interfaces (Modbus, Profibus, Ethernet/IP) to enable remote monitoring and diagnosis.
- Safety Protection: The enclosure meets IP54 protection grade, and internal components comply with IEC 60947-4-1 standard, providing reliable overload, short-circuit and undervoltage protection.
- Energy-efficient Heat Dissipation: The internal structure adopts forced air cooling or natural convection design, combined with heat sinks to ensure temperature control under high load conditions.
3. Structure & Composition
- Cabinet Body: Cold-rolled steel plate stamping forming with anti-corrosive paint spraying on the surface, providing sturdy mechanical support.
- Busbar System: Copper or aluminum busbars fixed by elastic buckles, facilitating quick assembly, disassembly and module replacement.
- Functional Modules (including but not limited to):Operation Panel: Optional knobs, buttons, touch screens or indicator lights, supporting local manual operation and status display.
- Circuit breaker modules (Miniature Air Circuit Breaker, Miniature Vacuum Circuit Breaker)
- Contactor/relay modules (with auxiliary contacts)
- Measurement & protection modules (current transformer, voltage transformer, power meter)
- Control & communication modules (PLC, Ethernet, Profibus, Modbus)
- Accessories (terminal block, grounding bar, fan, door lock, quick connector)
————————————————————————————————————-
