Allen-Bradley 1336-B005-EOD

1. Product Overview

2. Key Specifications

• Power Supply: Typically supports 380V–415V–460V three‑phase AC (50/60Hz).
• Power Rating: Estimated at 1.0–3.0 HP (approximately 0.75–2.2 kW). For exact values, refer to the unit’s nameplate.
• Dimensions: The EOD package generally falls in the medium‑power range, with approximate dimensions of 300mm x 160mm x 80mm.
• Cooling Method: Air‑cooled with Enhanced Open Design (EOD), providing improved heat dissipation.

___________________________________________________________________________________________________

3. Product Features

• High‑Performance Speed Control: Supports advanced vector control for smooth torque delivery and fast dynamic response.
• Communication Capabilities: Most 1336 series drives include or offer Ethernet/IP connectivity for seamless integration with PLCs and host systems.
• Modular Design: Allows for optional expansion modules such as operator panels and data acquisition modules.

___________________________________________________________________________________________________

4. Structure and Components

• Power Module: Converts voltage and frequency; the core of the drive.
• Control Panel: For parameter configuration, status monitoring, and local control.
• Communication Module: Enables network connectivity (e.g., Ethernet/IP).
• I/O Terminals: For motor connections and integration with external sensors such as limit switches and encoders.

___________________________________________________________________________________________________

5. Typical Applications

• General Variable Speed Control: Used for fans, pumps, and basic motor speed regulation.
• Precision Control: Ideal for textile machinery, packaging equipment, and other applications requiring accurate speed control.
• Industrial Automation: Integrates with PLCs to provide motion control in automated production lines.

___________________________________________________________________________________________________

6. Installation and Maintenance

Installation

• Environment: Although the EOD package offers strong heat dissipation, install in a well‑ventilated area to avoid heat buildup.
• Wiring: Ensure proper phase sequence, voltage, and frequency match the nameplate; verify secure grounding.
• Ventilation: Keep air intakes and exhaust areas unobstructed to maintain optimal cooling.

Maintenance

• Regular Cleaning: Remove dust to prevent clogging of cooling fans and heat sinks.
• Parameter Backup: Save configuration settings to a USB drive or PC to prevent loss during power failures.
• Troubleshooting: Use the drive’s fault codes and refer to the manual for efficient diagnostics.
