Allen-Bradley 1336-WB035

1. Overview

2. Specifications

• Model: 1336‑WB035
• Type: Brake Chopper
• Compatibility: Designed for Allen‑Bradley 1336 series drives (such as 1336F‑MCB, 1336L4, etc.). Must be used with a brake resistor or braking circuit.
• Electrical Characteristics: Uses internal chopping technology to control the release of braking energy.

3. Features

• Energy Management: Efficiently converts mechanical energy into electrical energy during braking and dissipates or feeds it back using chopping technology.
• Protection: Prevents damage or overheating of the drive caused by excessive braking energy, improving overall system reliability.
• Modular Design: Industrial‑grade plug‑in design for easy installation and replacement.

4. Structure & Components

• Chopper Power Transistor: Quickly switches or regulates current in the braking circuit.
• Heat Sink: Dissipates heat generated during chopping.
• Terminals: Connect to the drive’s main control board and the brake resistor (or braking circuit).

5. Application Fields

• Industrial Automation: Suitable for all control systems using Allen‑Bradley 1336 series drives.
• Mechatronics: Widely used in equipment requiring frequent braking, such as cranes, hoists, compressors, and packaging machinery.
• Motor Control: Provides essential energy management for large motors (30 HP and above) during start‑up and braking.

6. Installation & Maintenance

• Installation Location: Typically mounted on the side or back of the drive, connected to the main control board via cables or plug‑in connectors.
• Installation Requirements: Ensure adequate ventilation and keep the heat sink free of obstructions.
• Maintenance Tips:
  • Regular Inspection: Check that the brake resistor and chopper transistor are functioning properly and not overheating.
  • Environmental Conditions: Avoid prolonged exposure to high temperatures, humidity, or corrosive gases.
  • Compatibility: Must be used with Allen‑Bradley 1336 series drives and their matching braking circuits (e.g., 1336‑BDB‑SP79D). It cannot be used alone.
