Allen-Bradley 1336F-AQF05-AA AC Variable Frequency Drive
Allen-Bradley 1336F-AQF05-AA
1. Product Overview
Allen-Bradley 1336F-AQF05-AA is an AC Variable Frequency Drive (VFD) product under the Allen-Bradley brand of Rockwell Automation. This series of VFDs adopts a modular design and is usually used with the L series (drive) or T series (panel) of the 1336 series to adjust the speed and control functions of AC motors.
Power and Configuration: Power rating of approximately 5 HP (about 3.73 kW). It supports standard input voltage of 380-480V.
Main Functions: Supports multiple control modes such as V/Hz control and vector control, enabling frequency conversion speed regulation, forward and reverse control, braking regeneration, and soft start of the motor.
_____________________________________________________________________________
2. Core Parameters
Power Rating: 5 HP (approximately 3.73 kW).
Power Supply Voltage: 380-480V three-phase AC.
Control Modes: V/Hz control, vector control (depending on specific model).
Input/Output: Digital I/O terminals are used to receive PLC control signals, and analog I/O is used for speed setting and status feedback.
_____________________________________________________________________________
3. Product Features
Modular Design: This series adopts a modular structure (such as 1336/1336VT panels), facilitating on-site maintenance and function expansion.
Precise Control: Equipped with digitally precise speed control and parameter programming functions, supporting non-volatile memory to prevent parameter loss after power failure.
Remote Programming: Parameters can be set, status displayed, and fault diagnosed through 1336/1336VT remote programming panels (RP1, RP2, RP3 options), improving on-site commissioning efficiency.
_____________________________________________________________________________
4. Structure and Composition
Main Unit: Installed in the control cabinet, directly connected to the power supply and motor.
Remote Programming Panel (e.g., 1336VT): Installed on the on-site operation console for parameter display and manual control.
Communication Module: Industrial network communication modules such as Ethernet/IP and DeviceNet can be installed as needed to achieve network integration with PLC or upper computer.
_____________________________________________________________________________
5. Main Application Fields
Mechanical Manufacturing: Used for spindle speed control of machine tools such as lathes, milling machines, and drilling machines.
Printing and Packaging: Controls the speed of printing machines and packaging line conveyors.
Paper Making and Textile: Used for variable speed operation of paper machine calenders and textile machinery.
General Automation: Widely used for motor drive control in various industrial automation production lines.
_____________________________________________________________________________
6. Installation and Maintenance Recommendations
Installation Location: The VFD should be installed in a well-ventilated, moisture-proof, and dust-proof environment. If used in an industrially polluted environment, it is recommended to select a model with a higher protection level (such as adding IP56 or IP54 enclosure).
Wiring Requirements: Strictly follow the electrical wiring diagram for wiring to ensure reliable main power wiring and avoid damage caused by voltage fluctuations.
Heat Dissipation Management: The VFD generates heat during operation; it is necessary to ensure that its heat dissipation holes are not blocked, and additional fans or radiators should be installed if necessary.
Parameter Setting: After installation, parameters should be set according to motor specifications (power, rated speed, torque, etc.) and load characteristics to prevent overload and motor damage.
Troubleshooting: When a fault occurs, diagnosis can be performed through the error code displayed on the panel or by querying parameters through the network. Common faults include overcurrent, overvoltage, and overheating.
————————————————————————————————————-
