Allen-Bradley 1336F-C040-AA-E

1. Product Overview

2. Key Specifications

• Operating Voltage (AC): Typically supports 120VAC.
• Rated Current: Between 10A and 40A.
• Switching Characteristics: Solid‑state design with no mechanical contacts; switching is performed entirely by semiconductor devices.
• Power Consumption: Minimal mechanical wear; power loss mainly occurs in the control circuit.

_______

3. Product Features

• No Mechanical Contacts: Uses semiconductor switching for ultra‑fast response times (typically in milliseconds) and eliminates contact bounce.
• Long Service Life: Without mechanical wear, the theoretical lifespan is significantly longer than traditional electromechanical contactors.
• High Shock Resistance: Capable of handling high‑frequency switching, suitable for pulsed loads such as transformer control.
• Compact Size: Solid‑state construction allows for a more space‑saving design compared to conventional contactors.

__________

4. Construction and Components

• Input (Control Side): Receives external control signals (e.g., from a PLC output). Typically includes a control LED and an optocoupler for isolation.
• Output (Power Side): Consists of thyristors, Triacs, or other power semiconductors that switch the actual load circuit.
• Cooling Structure: Power semiconductors generate heat during operation, so heat sinks or thermal terminals are usually integrated.
• Terminals: For connecting both the control circuit and the load circuit.

_________

5. Application Areas

• Industrial Automation: Used with PLC outputs to control various loads.
• Motor Control: Controls the activation of asynchronous motors or variable frequency drives (VFDs).
• Heating Systems: Manages resistive heaters or hot air blowers.
• Lighting Control: Controls industrial lighting or stage lighting systems.
• Transformer Protection: Prevents DC voltage from entering the power grid due to its unidirectional conduction characteristics.

________

6. Installation and Maintenance

Installation

• DIN Rail Mounting: This model is typically designed for DIN rail installation, allowing easy snap‑on mounting inside electrical control cabinets.
• Wiring: Carefully distinguish between control‑side terminals (low voltage, low current) and load‑side terminals (high voltage, high current) to avoid miswiring.

Maintenance

• Check Cooling: Solid‑state switches generate heat during operation. Regularly inspect heat sinks for dust accumulation or poor heat dissipation.
• Replacement: SSRs require minimal maintenance compared to mechanical contactors. Replacement is typically only needed if the unit fails or reaches the end of its service life.
