Allen-Bradley 2094-BC07-M05-M

1. Overview

2. Specifications

• Input Voltage: 324 ~ 528 V three-phase AC (360 ~ 480 V commonly used)
• Rated Power: 22 kW (with an output current of approximately 45 A)
• Output Current: 45 A continuously, with a peak value of up to 67.7 A
• Operating Temperature: 0 ~ 50 ℃
• Dimensions: 7.7 × 11.9 × 16.7 inches (with a minimum enclosure depth of approximately 302 mm)
• Weight: Approximately 22 lb (10 kg)
• Compatible Circuit Breakers: FNQ‑R‑10, FNQ‑R‑7.5, 1492‑SPM2D060, 1492‑SPM1D150
• Communication Interfaces: EtherNet/IP, SERCOS, DPI (optional)

3. Product Features

• High Power Density: It provides a high power of 22 kW in a compact size, making it suitable for cabinets with limited space.
• Multi-Protocol Compatibility: It supports EtherNet/IP, SERCOS, and DPI, facilitating integration with various controllers.
• Safe Torque Off: It automatically cuts off the output in abnormal situations to protect the safety of equipment.
• Modular Design: It can be combined with other Kinetix 6000 axis power modules to achieve multi-axis synchronous control.
• Industrial-Grade Reliability: It complies with the IEC 61800‑5‑2 standard and comes with a 2-year industrial warranty.

4. Structure and Composition

• Power Input Terminal: It has three-phase input terminals equipped with fuses (FNQ‑R‑10/7.5).
• Power Conversion Unit: It includes internal inverters and rectifiers to realize AC-DC-AC energy conversion.
• Output Terminal: It provides high-current three-phase output for connection to servo motors.
• Communication Interface Board: It is equipped with EtherNet/IP, SERCOS, and DPI interface modules.
• Heat Dissipation System: It consists of internal heat sinks and external fans (optional) to maintain the operating temperature.
• Chassis: It has a metal enclosure with IP20 protection rating, suitable for standard DIN rails.

5. Application Fields

• CNC machine tools (turning, milling, grinding)
• Packaging and printing equipment
• Automated assembly lines
• Robot joint drives
• High-speed textile and spinning machinery
• Any industrial automation systems that require high-precision and multi-axis synchronous motion control

6. Installation and Maintenance

Installation

1. Fix the module on a standard 35 mm DIN rail, ensuring the rail is horizontal and has sufficient heat dissipation space.
2. Connect the three-phase power supply according to the electrical diagram, using fuses or circuit breakers that meet the specifications.
3. Connect to the PLC/motion controller via the corresponding communication interface (EtherNet/IP, SERCOS, DPI).
4. Check the wiring marks to ensure correct phase sequence and grounding, and comply with the IEC 60204‑1 safety standards.

Commissioning

1. Conduct a no-load inspection before startup to ensure there is no abnormal noise or overheating.
2. Configure parameters (current limit, acceleration/deceleration time, fault protection, etc.) in the control software.
3. Verify the positioning, speed, and torque response of the servo motor through closed-loop testing.

Maintenance

1. Regularly check the tightness of the wiring terminals to prevent poor contact caused by looseness.
2. Clean the dust on the module surface every 12 months to ensure the heat dissipation channels are unobstructed.
3. Monitor the operating temperature and current. If abnormal temperature rise or overcurrent alarm occurs, stop the machine immediately for inspection.
4. Replace the internal fuses or fans (if any) according to the manufacturer’s recommendations, and maintain spare parts inventory.

————————————————————————————————————-
