1. Core Overview

2. Key Technical Parameters

• Model/Part Number: PF-3110S-S4/7
• Supported Tools: Specifically matched with Atlas Copco Tensor S4 and Tensor S7 series electric torque tools
• Main Control Modes:

  Communication Interfaces: Supports Ethernet, RS-232, RS-485

  • Torque Control: Accurately reach the set torque value
  • Angle Control: Rotate to the set angle
  • Combined Control: Combined mode of torque and angle
• Data Functions: Batch statistics, fault alarm, traceable data storage
• Power Requirement: Usually 24V DC

_______________________________________________________________________________________________________

3. Main Product Features

• Multi-Protocol Support: Compatible with various industrial communication protocols, facilitating access to different automation systems.
• Precise Control: Based on Atlas Copco’s core technology, it provides extremely high tightening accuracy and significantly reduces Torque Variation.
• Data Recording: Real-time recording of assembly process data, supporting quality traceability and process optimization.
• Software Compatibility: Compatible with Atlas Copco’s process management software such as ToolsTalk, supporting offline programming and online monitoring.

_______________________________________________________________________________________________________

4. Structure and Composition

• Host Unit: Core processor and display screen, responsible for parameter setting and process display.
• Communication Module: Realizes data interaction with upper computer or PLC.
• Power Supply Module: Responsible for power conversion and power supply.
• Input/Output Interfaces: Used to connect torque tools, signal lights, alarms and other accessories.

_______________________________________________________________________________________________________

5. Typical Application Fields

• Automotive Manufacturing: Engine assembly, chassis assembly, door and body welding structures, etc.
• Aerospace: Airframe structure, engine assembly, etc.
• Railway Transportation: Train body, wheel and brake system assembly.
• Heavy Machinery: Assembly of large machine tools, compressors, fans, etc.

_______________________________________________________________________________________________________

6. Installation and Maintenance Recommendations

Installation

• Ensure the installation position is stable to avoid the impact of vibration.
• Strictly follow the wiring diagram during wiring, especially the wiring specifications of communication interfaces (Ethernet/RS-232/RS-485).
• Confirm that the power supply voltage matches the rated voltage of the controller and that the grounding is good.

Maintenance

• Regularly check the connection status of terminal blocks and communication ports to prevent looseness or oxidation.
• Perform regular calibration and verification to ensure the accuracy of the controller’s torque and angle readings.
• Software Upgrade: Regularly check for firmware updates or software patches released by Atlas Copco to obtain the latest function optimizations and security patches.
