ATLAS PF3109-C-DN-HW Analog Output Module
ATLAS PF3109-C-DN-HW
1. Overview
The PF3109-C-DN-HW is a high-power model in the Atlas Copco Power Focus 3100 series. Its main function is to realize advanced control of electric tightening tools through precise torque and angle control. It supports multiple communication protocols (such as DeviceNet, EtherNet/IP, etc.) and is suitable for high-demand industrial automation applications.
___________________________________________________________________________________________________________________________
2. Specifications
- Rated Power: Approximately 300W
- Input Power Supply: AC 100–240V, 50/60Hz
- Control Mode: Torque, Angle, and Combined Control
- Communication Interface: DeviceNet (DN), also supports other industrial bus protocols
- Storage Capacity: Supports storing a large number of tightening programs, usually more than 255
___________________________________________________________________________________________________________________________
3. Product Features
- High-Precision Control: It can precisely control torque and angle to ensure tightening quality.
- Powerful Communication Capability: Built-in DeviceNet interface, easy to integrate into industrial networks for data collection and remote monitoring.
- Flexible Installation Methods: Supports DIN rail or panel mounting, adapting to various industrial environments.
- Modular Design: Hardware is modular, making it easy to maintain and upgrade.
___________________________________________________________________________________________________________________________
4. Structure and Composition
The device is mainly composed of a controller body, a communication module (DeviceNet), and a power module. The controller body internally includes a CPU, memory, and I/O interface, which are used to receive instructions from PLC or upper computer and control the operation of electric tools.
___________________________________________________________________________________________________________________________
5. Application Fields
- Automotive Manufacturing: Precision tightening of body, chassis, and engine components.
- Aerospace: High-precision tightening of key structural parts.
- Home Appliances and Electronics: Automated assembly of screws.
- Construction Machinery: Quick installation of large equipment components.
___________________________________________________________________________________________________________________________
6. Installation and Maintenance
Installation
It is usually installed by DIN rail or panel embedding. During installation, ensure correct connection with power lines and communication lines, and check whether the grounding is good.
Maintenance
Regularly check communication connections, clean radiators, and inspect the working status of internal electronic components. Since this model is mainly an electronic control device, it usually does not involve mechanical wear, but it is necessary to prevent the impact of dust and humid environments on electronic components.
————————————————————————————————————-
If you would like to learn more about our products and services, please feel free to contact us at any time!
- Sales Manager : Jinny
- Email : sales5@xrjdcs.com
- Whatsapp/Mobile:+86 15359273791
