ATLAS PF4002-G-EIP-HW Industrial Module
ATLAS PF4002-G-EIP-HW
1. Product Overview
The PF4002-G-EIP-HW is a specific hardware configuration within the Atlas Copco PF4000 series of controllers (EIP stands for EtherNet/IP communication protocol). It is a control and monitoring unit designed for electric assembly tools, featuring a graphical user interface that facilitates easy setup and monitoring for operators.
___________________________________________________________________________________________________________________________
2. Parameters & Technical Specifications
|
Parameter Category
|
Details
|
|---|---|
|
Communication Protocol
|
Supports EtherNet/IP (EIP); optional Open Protocol, PROFINET, USB, RS232, etc.
|
|
Power Supply Requirements
|
Suitable for single-phase 110V or 230V AC power supply, with automatic power voltage sensing.
|
|
Tool Compatibility
|
Compatible with Atlas Copco Tensor series electric tightening tools.
|
|
User Interface
|
Equipped with an advanced graphical interface, supporting real-time data recording and traceability analysis.
|
|
Installation Requirements
|
Compact design, suitable for installation in industrial control cabinets.
|
___________________________________________________________________________________________________________________________
3. Product Features
- Multiple Tightening Strategy Support: Supports angle control, torque control, and combined control strategies.
- Highly Scalable: Supports multi-channel expansion and automatic tool identification, adapting to complex processes and multi-task operation scenarios.
- Real-Time Data Traceability: Features real-time data recording function, facilitating quality control and process optimization.
- Advanced Communication Capability: Built-in EtherNet/IP communication module, supporting high-speed industrial network communication.
- Safety & Reliability: Equipped with anti-static discharge (ESD) design, along with complete safety warnings and maintenance guidelines.
___________________________________________________________________________________________________________________________
4. Structure & Composition
- Main Unit: Core control unit integrating processor, memory, and communication module.
- Display/Operation Panel: Used for displaying real-time data and setting parameters.
- Input/Output Interfaces: Including Ethernet (EIP), USB, RS232 interfaces, etc., for connecting external devices or networks.
- Tool Connection Interface: Used for connecting Atlas Copco electric tightening tools.
___________________________________________________________________________________________________________________________
5. Application Fields
- Automotive Manufacturing: Assembly of key components such as engines, gearboxes, and chassis.
- Aerospace Industry: High-precision tightening of bolted connections for aircraft structural components.
- Electronic Product Assembly: Assembly lines requiring multi-station process control and traceability.
- High-Reliability Industrial Connection Scenarios: Such as electrical equipment production.
___________________________________________________________________________________________________________________________
6. Installation & Maintenance
Installation
Due to its compact structure, the controller is usually installed inside industrial control cabinets or control boxes of production lines. During installation, ensure good grounding and make connections in accordance with the wiring diagram in the user manual.
Maintenance
Perform regular anti-static discharge (ESD) maintenance and check the tightness of communication interfaces and power connections. The product warranty period is usually valid when the electric motor is not opened.
————————————————————————————————————-
