Schneider ATS48C48Y Soft Starter
Schneider ATS48C48Y
The ATS48C48Y is a high-performance soft starter belonging to theAltistart ATS48 Series by Schneider Electric, a global leader in industrial automation and electrical solutions. Engineered to meet the rigorous demands of heavy-duty, high-inertia and high-stress industrial environments, this soft starter is widely deployed in heavy industries including cement, steel, petrochemical, mining, and high-power pump applications. Its core function is to precisely regulate motor starting current, minimize grid impact, and extend the service life of motors and transmission equipment, delivering stable and efficient motor control for industrial operations.
______________________________________________________________________________________________________________
1. Product Overview
As a premium offering in Schneider Electric’s Altistart ATS48 lineup, the ATS48C48Y soft starter is purpose-built for heavy industrial scenarios where conventional motor starting methods fail to meet performance and reliability standards. Unlike traditional direct-on-line starting that causes severe current surges and mechanical shocks, this unit delivers smooth, controlled motor acceleration and deceleration, protecting both the power grid and connected machinery. It is optimized for high-power, high-torque equipment, making it an ideal choice for critical industrial processes that require consistent, reliable motor operation.
______________________________________________________________________________________________________________
2. Technical Specifications
|
Parameter
|
Specification
|
|---|---|
|
Rated Current
|
480A
|
|
Rated Power
|
900 kW (Approx. 1200 HP)
|
|
Rated Voltage
|
208 – 690 V AC
|
|
Operating Ambient Temperature
|
-10°C to +60°C
|
|
Storage Ambient Temperature
|
-25°C to +70°C
|
|
Protection Degree
|
IP20 (Indoor Installation Only)
|
|
Communication Interfaces
|
RS485 (Modbus RTU), USB
|
|
Core Functions
|
Soft Start, Soft Stop, Bidirectional Torque Limitation, Stepless Current Limitation, Overload Protection
|
|
Control Power Supply
|
24V DC (For Internal Logic & Relay Control)
|
______________________________________________________________________________________________________________
3. Product Features & Advantages
3.1 Core Technical Superiority
Patented TCS Torque Control Technology: The ATS48C48Y adopts Schneider Electric’s exclusive Torque Control System (TCS) gradient control technology, replacing traditional voltage ramp starting methods. This innovative technology enables smoother, more precise motor starting control, eliminating mechanical jitters and current spikes that are common with conventional soft starters.
Bidirectional Torque Limitation: Beyond standard starting current limitation, this unit supports current limitation during motor stopping, making it perfectly suited for heavy-duty applications and frequent start-stop operating conditions that demand enhanced control stability.
High-Precision Current Limitation: The starting current can be accurately limited to approximately 2.5–3 times the rated current, drastically reducing impact on the power grid and motor components, while preventing grid voltage fluctuations and equipment wear.
______________________________________________________________________________________________________________
3.2 Reliability & Comprehensive Protection
All-Round Motor Protection: Equipped with multiple built-in protection functions, including overcurrent, overvoltage, undervoltage, short circuit, overload, and over-temperature protection. This full-suite protection system safeguards the motor and soft starter from damage caused by abnormal operating conditions, minimizing downtime and maintenance costs.
Heavy-Duty Operational Capability: Custom-designed for heavy-load and high-inertia industrial equipment, the ATS48C48Y delivers exceptional resilience, adapting to harsh industrial environments and unstable power grid conditions without compromising performance.
_______________________________________________________________________________________
3.3 Intelligence & Communication Capabilities
Intelligent Diagnostic Function: Built-in real-time diagnostic capabilities monitor equipment operating status continuously, with fault and operational data transmissible via the RS485 interface (supports Modbus RTU protocol) for remote monitoring and centralized control.
Convenient Parameter Configuration: Features a USB interface for fast parameter import and export, allowing quick replication of parameter settings across identical operating scenarios. This streamlines commissioning and on-site setup, saving time for installation and maintenance teams.
______________________________________________________________________________________________________________
4. Structure & Components
- Power Module: Integrates main contactors for the primary circuit, responsible for carrying high-current loads and ensuring stable power transmission to the motor.
- Control Board: Built-in high-performance microprocessor that executes advanced starting algorithms, real-time status monitoring, and fault diagnostic functions, ensuring precise and reliable operation.
- Power Diodes: Core components for voltage regulation and current control, enabling smooth and accurate motor speed adjustment during starting and stopping.
- Cooling System: Adopts air cooling or heat sink design (model-specific) to efficiently dissipate heat, maintaining stable performance even under continuous high-load operation.
- Interface Panel: Equipped with a clear display screen, control buttons, RS485 communication port, and power socket, facilitating intuitive operation, parameter adjustment, and external connectivity.
______________________________________________________________________________________________________________
5. Typical Application Areas
The Schneider ATS48C48Y soft starter is engineered for heavy industrial applications requiring high-power motor control, with core application scenarios including:
- Cement & Limestone Mills: Handles high-torque, heavy-load starting for grinding equipment, ensuring stable startup under extreme load conditions.
- Pump Equipment: Ideal for booster pumps, water pumps, and other fluid delivery equipment, especially suited for frequent start-stop pumping operations.
- Mining & Metallurgical Equipment: Applied to crushers, industrial fans, rollers, and other heavy mining and metallurgical machinery.
- Petrochemical Industry: Used for various compressors, centrifuges, and transfer pumps in petrochemical processing plants, delivering reliable motor control in critical production links.
————————————————————————————————————-
