B&R 5AP1120.1043-000

The 5AP1120.1043-000 is an embedded panel PC belonging to B&R’s AP1000 series. It features a 10.4-inch color TFT display with AMT touch technology, designed for local human-machine interaction (HMI) in industrial automation control systems. The product complies with CE, cULus, and HazLoc Class 1 Division 2 certifications, enabling long-term reliable operation in harsh industrial environments.

Main Technical Specifications

• Display: 10.4-inch TFT with 16.2 million colors; resolution of 640 × 480 pixels (VGA); contrast ratio of 900:1; viewing angle of 80° (horizontal/vertical); LED backlight with brightness ranging from 22.5 to 450 cd/m²; half-brightness lifespan of approximately 70,000 hours.
• Touch Method: AMT (optical multi-touch) with a light transmittance of 81% ± 3%.
• Controller: B&R self-developed controller with a serial 12-bit interface.
• Interfaces: USB 2.0 Type-A (supporting low speed of 1.5 Mbit/s, full speed of 12 Mbit/s, and high speed of 480 Mbit/s) with a maximum current of 500 mA.
• Protection Rating: IP65 for the front panel; IP20 for the rear panel when connecting modules or system units are installed. Indoor use only, compliant with UL 50 standards.
• Mechanical Structure: Housing made of natural anodized aluminum; keyboard overlay made of polyester material; appearance colors in RAL 9006 (background) and RAL 7024 (bezel).
• Dimensions & Weight: 323 mm (width) × 260 mm (height); weight of approximately 2.8 kg.
• Power Supply: 24 V DC input; internal 5 V DC output.

Product Features

• High Reliability: Equipped with an IP65 front panel, industrial-grade aluminum alloy housing, and HazLoc certification, making it suitable for harsh environments with dust and humidity.
• Excellent Display & Touch Performance: Large-size, high-brightness TFT display combined with AMT multi-touch technology delivers a clear, wide-viewing-angle operation interface.
• Rich Interfaces: Offers multiple industrial communication options such as USB 2.0 and serial 12-bit interfaces, facilitating integration with external devices like PLCs and sensors.
• Compact & Lightweight: Weighing only 2.8 kg, it is easy to install inside cabinets or control boxes with minimal space occupation.
• Compliance with Multiple International Certifications: Meets CE, cULus, and HazLoc Class 1 Division 2 standards, satisfying regulatory requirements in global markets.

Structure & Composition

• Display Module: TFT screen + LED backlight.
• Touch Layer: AMT optical touch sensing layer.
• Control Unit: B&R self-developed CPU and I/O interface board.
• Housing: Aluminum alloy shell with an internal polyester keyboard overlay.
• Power Module: Converts 24 V DC input to internal 5 V DC output.
• Interface Board: Includes USB, serial, and reserved expansion interfaces.

Typical Application Fields

• Machine vision and image processing stations
• Local HMI for production lines
• Automated assembly and inspection systems
• Process control and monitoring panels
• Operation panels for robots and CNC machine tools

Installation & Maintenance Guidelines

• Installation Method: Panel-mounted or embedded installation is available. It is recommended to fix the device to pre-drilled holes in cabinets or control boxes using screws to ensure the IP65 protection of the front panel remains intact.
• Power Wiring: Use a 24 V DC regulated power supply. Ensure power cables comply with IEC 60320 standards to prevent system interference caused by voltage fluctuations.
• Grounding & Shielding: The housing must be reliably grounded. It is advisable to use shielded cables for signal lines of USB and serial interfaces to reduce electromagnetic interference.
• Protection Inspection: Regularly check the front panel’s sealing gasket to maintain complete IP65 protection. Ensure the rear panel retains IP20 protection after module assembly to prevent dust ingress.
• Firmware Upgrade: Perform firmware updates via B&R Automation Studio or a web interface. Back up the current configuration before upgrading.
• Cleaning & Maintenance: Wipe the display surface gently with a soft dry cloth or slightly damp cloth. Avoid using strong acid or alkaline cleaners to prevent damage to the screen and touch layer.

————————————————————————————————————-
