B&R 5AP920.1505-01 Automation Panel
B&R 5AP920.1505-01
1. Overview
The 5AP920.1505-01 is a high-performance industrial automation panel (from the Automation Panel 900 series) launched by B&R Automation. It integrates a 15-inch XGA color TFT display, an analog resistive touchscreen, and multiple industrial interfaces. Designed specifically for harsh on-site environments, it is suitable for monitoring and controlling machines, processes, and facilities.
2. Main Specifications
| Category | Details |
|---|---|
| Display | 15″ TFT color LCD, resolution 1024 × 768 (XGA), contrast ratio 1000:1, brightness 400 cd/m², viewing angle 85° (horizontal/vertical) |
| Touch Technology | Analog resistive, operable with fingers, gloves, or a stylus |
| Interfaces | 3 × USB 2.0, Ethernet (10/100 Mbps), RS‑232, optional DVI‑D receiver |
| Power Supply | 24 V DC, typical power consumption approx. 24 W |
| Environment | Operating temperature 0 °C ~ +50 °C, storage temperature –20 °C ~ +60 °C, humidity 5 % ~ 95 % (non-condensing), front panel protection class IP65 |
| Dimensions/Weight | Approx. 380 mm × 285 mm × 80 mm, weight approx. 4.5 kg |
3. Product Features
- High-brightness and wide-viewing-angle display, ensuring clear information readability even in strong light environments.
- Robust metal housing that meets industrial protection standards (IP65), adapting to harsh on-site conditions.
- Integrated multiple interfaces, supporting on-site local control, remote monitoring, and video transmission.
- Modular design, enabling function expansion via the Automation Panel Link (APL) protocol for easy system upgrades.
- Easy integration, compatible with B&R Automation Studio and other B&R controllers to achieve rapid engineering deployment.
4. Structure and Composition
- Display Module: TFT color screen, LED backlight.
- Touch Layer: Analog resistive touch-sensitive layer.
- Main Control Board: Built-in industrial-grade processor, storage (RAM/Flash), and I/O interfaces.
- Communication Board: Interface modules for Ethernet, RS‑232, USB, and optional DVI‑D.
- Power Supply Module: 24 V DC input voltage stabilization circuit.
- Housing and Mounting Bracket: Metal housing, DIN rail or wall-mounted structure.
5. Typical Application Areas
- Machine Control: CNC machine tools, assembly lines.
- Process Control: Monitoring of chemical, food and beverage, and pharmaceutical processes.
- Facility Management: Energy management, building automation.
- Data Acquisition and Monitoring: On-site HMI, real-time parameter display.
- Remote Diagnostics: Remote maintenance and fault diagnosis via Ethernet.
6. Installation and Maintenance Points
- Installation Method: Panel-mounted or wall-mounted installation is available; ensure the DIN rail is fixed securely.
- Wiring Notes: The 24 V DC power supply must meet the rated current; use shielded wires for signal cables to reduce electromagnetic interference.
- Environment Check: Ensure the installation location meets IP65 protection requirements to prevent direct intrusion of moisture or dust.
- Initial Commissioning: Use B&R Automation Studio for parameter configuration, and check the connectivity of all communication ports.
- Daily Maintenance: Regularly clean the touchscreen surface and check the tightness of USB and Ethernet interfaces; perform power-off protection before long-term shutdown.
- Fault Diagnosis: Use the panel’s built-in diagnostic function to view error codes; if necessary, remotely access logs via Ethernet for analysis.
————————————————————————————————————-
