B&R 5PP520.1214-00

Overview

Technical Specifications (Excerpted from Official Datasheet)

• Power Supply: 24 V DC ± 25%
• Rated Current: 1.2 A, with a maximum power consumption of 29 W
• Display: 12.1-inch TFT color display, featuring a resolution of 800 × 600 px, a brightness range of 45‑450 cd/m², and LED backlighting
• Touch Function: Equipped with AMT technology, a 12-bit serial interface, and a light transmittance of 81 % ± 3%
• Interfaces: COM1 (RS‑232, 9-pin D‑SUB, 115 kbit/s), CompactFlash, SD card, 3×USB 2.0, and Ethernet (10/100/1000 Mbit/s)
• Protection Class: IP65 (dust-tight and protected against water jets)
• Operating Temperature: -20 °C ~ +60 °C; Storage Temperature: -40 °C ~ +85 °C
• Dimensions/Weight: Approximately 307 mm × 210 mm × 80 mm, with a weight of around 2.5 kg

Product Features

• Integrated Design: Combines display, touch, communication, and I/O functions in a single chassis, saving space and simplifying wiring.
• High Reliability: Incorporates multiple protection mechanisms such as IP65 protection, a watchdog timer, and power failure logic.
• Modular Expansion: Supports rear-mounted plug-in I/O, CF/SD memory cards, and various communication interfaces for easy function expansion.
• Easy Maintenance: The battery (Renata 950 mAh) is detachable and easy to replace; front-panel indicator lights provide real-time feedback on power, communication, and operation status.

Structure and Composition

• Main Chassis: Features a metal housing, with a power module, main control board, and display/touch subsystem inside.
• Display Subsystem: Consists of a 12.1-inch TFT screen and LED backlighting.
• Touch Subsystem: Includes an AMT touch layer and a 12-bit serial interface.
• Communication Module: Comprises RS‑232, USB, Ethernet, and CF/SD card slots.
• Battery and Indicator Lights: Includes an externally accessible lithium-ion battery and LED status indicators (for power, CF, connection, and operation).

Typical Application Areas

• Machine vision and human-machine interaction interfaces
• On-site process control and monitoring
• Local operation stations for automated assembly lines
• Visualization and debugging platforms for robotics and motion control

Key Points for Installation and Maintenance

Installation

1. Adopt DIN rail or wall-mounted installation.
2. Ensure the front of the chassis faces the operator and maintain good ventilation.

Wiring

1. Correctly connect the power supply, I/O, and communication cables according to the wiring diagram.
2. Use protective connectors to prevent loosening.

Debugging

1. After the first power-on, check the status of the LED indicator lights.
2. Once the system self-test is confirmed to pass, access B&R Automation Studio for configuration.

Maintenance

1. Regularly inspect the protective seals and clean the surface of the display screen.
2. The battery has a service life of approximately 4 years and should be replaced when a replacement prompt appears.

————————————————————————————————————-
