B&R 8BVI0220HCD0.000-1

1. Product Overview

2. Key Technical Specifications

3. Product Features

• High-Speed Communication: When paired with the X-Series bus, the cycle time can be as low as 30 µs, meeting the requirements of real-time control scenarios.
• Modular Structure: Enables flexible combination with other B&R I/O modules for scalable expansion and fast on-site replacement.
• Diagnostic Function: Built-in LED indicators display power supply, communication, and error status, facilitating convenient on-site maintenance.
• Anti-Interference Design: Optocoupler isolation and filter circuits enhance electromagnetic interference (EMI) resistance, ensuring stable and reliable signal transmission.
• Plug-and-Play Convenience: Supports automatic identification and configuration via B&R Automation Studio, significantly reducing engineering commissioning time.

4. Structure and Components

• Housing: Metal DIN-Rail mounting base that provides robust mechanical protection for internal components.
• Input Terminal Block: 8-channel screw terminals for fast and secure wiring operations.
• Internal Circuitry: Each channel is equipped with optocoupler isolation, filter capacitors, and surge protection to ensure signal integrity.
• Bus Interface: Standardized X-Series slot that enables high-speed fieldbus communication with the control system.
• Indicator Lights: LED indicators for real-time monitoring of power status, communication connectivity, and fault alerts.

5. Typical Application Fields

• Sensor signal acquisition in automated production lines
• Process control systems (valves, pumps, conveyor belts)
• Photoelectric sensors and limit switches in packaging equipment
• Access control and sensor networks in logistics systems
• Operation status indication of generators and frequency converters in energy management systems

6. Installation and Maintenance Guidelines

Installation

• Mount the module on a DIN-Rail and secure it quickly with screws or buckles.
• Ensure precise alignment of the slot when connecting to the X-Series bus to avoid incorrect insertion.

Wiring

• Use the screw terminals for wiring operations. Always cut off the power supply before wiring to ensure safety.
• Verify that the input voltage of each channel complies with the 24 V DC specification.

Commissioning

• Launch B&R Automation Studio; the system will automatically recognize the module and display the input status of each channel.
• Locate faults quickly by checking the LED indicator status.

Maintenance

• Regularly inspect the tightness of the terminal block and the integrity of the protective cover.
• In case of communication abnormalities, first check the bus connection and power supply status.
• For module replacement, simply pull the faulty module out of the slot and insert a new one—no additional configuration is required.
