1. Product Overview

Brand & Series

Product Positioning

2. Parameters & Technical Specifications

eTOP507U5P1

• Display Type: Capacitive touchscreen
• Screen Size: 5 inches, 16:9 widescreen design
• Resolution: 800 × 480 pixels
• Special Features: Equipped with U5P1 functional characteristics, supporting advanced PLC communication and stronger processing capability

eTOP507G

• Display Type: Resistive touchscreen, mainly relying on pressure touch
• Screen Size: 5 inches
• Resolution: 800 × 480 pixels
• Application Scenarios: More suitable for industrial scenarios requiring handwriting input or operation in harsh environments

___________________________________________________________________________________________________________________________

3. Product Features

• Industrial-Grade Durability: Both products adopt industrial-grade panels with IP54/65 dustproof and waterproof design, capable of adapting to harsh workshop environments.
• High Compatibility: Compatible with multiple PLC brands and communication protocols (such as MODBUS, Profibus, Profinet), facilitating integration into existing automation systems.
• Rich Functions: Support animations, trend charts, alarm systems, etc., to intuitively display equipment status.

___________________________________________________________________________________________________________________________

4. Structure & Components

• Main Panel: Includes display screen, touch layer, and industrial-grade cabinet.
• Communication Interfaces: Equipped with multiple communication interfaces (RS-232, RS-485, USB, Ethernet).
• Power & Control Unit: Integrates power module and processing chip internally.

___________________________________________________________________________________________________________________________

5. Application Fields

• Packaging Machinery: Used to monitor the operation status of packaging lines.
• Woodworking Machinery: Control CNC saws and other equipment.
• Textile Equipment: Used as the operation interface of textile machines.
• Food Processing: Monitor production line parameters.
• Other Mechanical Equipment: Such as CNC machine tools, injection molding machines, etc.

___________________________________________________________________________________________________________________________

6. Installation & Maintenance

Installation

Maintenance

• Regularly check the sensitivity of the touchscreen and the reliability of communication interfaces.
• Clean the panel surface, avoiding the use of corrosive detergents.

————————————————————————————————————-
