GE 115D2234G – IPU3-A

Product Overview

The GE 115D2234G is identified as an IPU3-A Volt Comp-PLU printed circuit board (PCB). Available component references associate this board with the IPU3-A assembly and the related number 117D8936G03.

As a board-level industrial automation component, it is designed for integration into compatible GE control equipment. Its compact PCB construction allows the board to perform its intended voltage compensation and related control functions within the larger system.

The 115D2234G can be considered when maintaining existing GE industrial control installations where an original or compatible replacement board is required.

Key Specifications

• Manufacturer: General Electric (GE)
• Board Type: Voltage Compensation PCB
• Assembly: IPU3-A
• Part Number: 115D2234G
• Related Reference: 117D8936G03
• Product Category: Industrial Control PCB
• Application: GE industrial control equipment
• Installation: System-integrated board assembly

Public component listings specifically describe 115D2234G as a “Volt Comp-PLU PCB” and associate it with IPU3-A.

Main Features

The board provides several practical advantages for industrial maintenance:

• Designed for use within compatible GE control systems.
• Compact printed circuit board construction.
• Supports voltage compensation-related control functions.
• Suitable for replacement and system restoration projects.
• Helps maintain the original control architecture without unnecessary system modification.
• Appropriate for industrial environments where reliable board-level control is required.

Because the exact electrical ratings can vary by system configuration, users should verify the equipment documentation and existing board markings before installation.

Structure and Components

The 115D2234G is a PCB-based control component rather than a standalone controller. Its construction typically includes the circuit board substrate, electronic components, connection points, and supporting circuitry required for its designated control function.

The board is associated with the IPU3-A assembly. Some listings also connect the assembly with 117D8936G03, which can be useful when cross-checking replacement requirements.

When sourcing a replacement, compare the complete part number, board revision, connector arrangement, and existing system configuration.

Typical Applications

The GE 115D2234G can be used in industrial control maintenance and replacement scenarios involving compatible GE equipment. Typical applications include:

• Industrial automation systems
• Control panel refurbishment
• Generator and power-control equipment
• Existing GE control-system maintenance
• PCB replacement and system restoration
• Industrial equipment modernization projects

Its primary value is in maintaining the functionality of established equipment without replacing an entire control assembly.

Installation & Maintenance

Before installation, disconnect the equipment from its power source and follow the applicable GE maintenance procedures. Check the replacement board for visible damage, contamination, or bent connectors.

During installation, ensure that all connectors are correctly aligned. Avoid excessive pressure on the PCB or its components. After installation, inspect wiring and connections before restoring power.

For long-term maintenance, keep the control cabinet clean and dry. Minimize dust, vibration, moisture, and excessive temperature exposure. If a fault occurs, compare the board revision and system configuration before replacing additional components.

Note: Publicly available sources confirm the 115D2234G/IPU3-A identification and its Volt Comp-PLU description, but detailed electrical specifications were not found in the available sources. Therefore, specific voltage, current, dimensions, and environmental ratings should be verified against the equipment’s original documentation before procurement or installation.
