GE 151X1235BC01SA41 Controller Module

Short Description:

The GE 151X1235BC01SA41 is a controller module manufactured by General Electric (GE), serving as a core component of the EX2100e excitation control system

FOB Price: US $0.5 - 9,999 / Piece

Min.Order Quantity: 100 Piece/Pieces

Supply Ability: 10000 Piece/Pieces per Month

Brand: GE

Manager: Jinny

E-mail: sales5@xrjdcs.com

Tel: + 86-15359273791

( WhatsApp )Wechat: + 86-15359273791

Warranty: one year

In stock: In stock

Send email to us Download as PDF

Product Detail

Product Tags

GE 151X1235BC01SA41

1. Product Overview

The GE 151X1235BC01SA41 is a controller module manufactured by General Electric (GE), serving as a core component of the EX2100e excitation control system. Its official design designation is “100MM SCR HS ASSEMBLY” (100mm Silicon-Controlled Rectifier High-Speed Assembly). As a dedicated spare part designed exclusively for GE gas turbine equipment, this module is also commonly referred to as an excitation board.

2. Product Features

High-Performance Controller Module: As a key part of the GE automated control system, it is tailored for industrial scenarios that demand ultra-high reliability and operational stability.

HART Protocol Support: The module is fully compatible with the HART communication protocol, enabling standardized data interaction and universal adaptability in industrial automation applications.

Integrated I/O Functions: It integrates comprehensive digital and analog input/output modules to realize diversified signal acquisition and control output functions.

High Reliability and Precision: Optimized for the EX2100e excitation control system, the module delivers excellent operational stability and high control precision in long-term industrial operation.

3. Structure and Composition

No specific data on the internal structural composition of the 151X1235BC01SA41 board is available from existing public resources. Based on the overall architecture of the GE EX2100e excitation control system, the complete system consists of three core parts:

Central controller unit
Field I/O unit
Human-machine interface unit

As a core excitation board, the 151X1235BC01SA41 is generally installed in the power conversion cabinet and works in coordination with PCM (Power Control Module), DC contactors, and circuit breakers to complete system excitation control and power regulation.

4. Application Fields

The 151X1235BC01SA41 board is widely applied in the following industrial and power industry scenarios:

Gas Turbine Excitation Control: Acts as a core control component for the excitation system of GE gas turbine units, supporting stable operation of turbine equipment.
Power Generation Units: The matched EX2100e system is applicable to new-built and renovated steam turbines, gas turbines, and hydroelectric generators.
Industrial Automation: Suitable for all types of industrial automation scenarios requiring high stability and high-reliability control systems.
Power Infrastructure: Widely used in power electronic equipment and frequency converter systems in power plants and substations.

5. Technical Parameters

Detailed official technical parameters of the module have not been publicly specified, including but not limited to the following indicators:

Power supply voltage
Operating temperature range
Current and voltage capacity
Number of input and output channels
Types of communication interfaces
Power consumption parameters

6. Installation and Maintenance

No detailed official installation procedures and standardized maintenance guidelines for this single module are available in public data. Combined with the general technical characteristics of the EX2100e excitation control system, the overall system features are summarized as follows:

Modular Design: The controller adopts a compact modular structure, which features simple and convenient installation and effectively saves cabinet space.

Triple Modular Redundancy (TMR): The system supports TMR configuration, which eliminates single-point faults and significantly improves operational reliability and stability.

Anti-Interference Performance: Partial board cards of the EX2100e system are equipped with optical fiber isolation design, realizing effective voltage isolation and strong anti-noise interference capability.

Maintenance Precautions: The system faces the risk of unit tripping caused by interference on auxiliary I/O boards. It is recommended to implement targeted anti-electromagnetic interference transformation solutions to ensure safe and stable unit operation.

————————————————————————————————————-
