GE 6KG1143005X1B1 Variable Frequency Drive
GE 6KG1143005X1B1
The GE 6KG1143005X1B1 is a classic 5 HP (3.75 kW) variable frequency drive (VFD) belonging to the AF-300G11 series, manufactured by Fuji Electric under General Electric (GE). This drive is mainly used to control the start-stop, speed regulation and reverse operation of induction motors, and is widely applied in air conditioning, ventilation, pumping systems, light machinery and other related fields.
______________________________________________________________________________________________
Core Specifications & Performance
|
Parameter
|
Specification/Description
|
|---|---|
|
Model
|
6KG1143005X1B1
|
|
Rated Power
|
5 HP (Approx. 3.75 kW)
|
|
Voltage Rating
|
380/480 VAC
|
|
Phase
|
3-Phase
|
|
Phase Rotation
|
U/D
|
|
Frequency Range
|
0-70 Hz (Maximum Frequency)
|
|
Rated Current
|
13.6 A
|
|
Power Factor
|
0.98
|
|
Dimensions
|
214 × 94 × 215 mm
|
|
Cooling Method
|
Forced Air Cooling (with Built-in Fan)
|
|
Operating Ambient Temperature
|
-5℃ to 45℃
|
|
Protection Rating
|
IP20 (Non-dust-tight and Non-waterproof)
|
|
Drive Type
|
AC Speed Controller (AF-300 Series)
|
______________________________________________________________________________________________
Product Features
Compact and Lightweight Structure: Adopts a compact box-type design for easy installation, transportation and space-saving placement in various equipment setups.
High Efficiency and Energy Saving: Built on proven VFD technology, the drive controls motor speed by adjusting the power supply frequency, delivering remarkable energy-saving performance for industrial and commercial applications.
User-Friendly Operation: Equipped with a digital keypad (such as TP-G9S-UX) for direct parameter setting and manual control, featuring an intuitive interface and straightforward operation.
Superior Reliability: As a classic product line from Fuji Electric, this series has over 20 years of field verification, with strong anti-interference capability and stable, long-lasting performance.
______________________________________________________________________________________________
Structure & Components
Main Unit: The core part of the drive, including power modules, DC bus, inverter bridge arms and cooling fan, responsible for power conversion and motor control.
Control Panel:
- Keypad: Models such as TP-G9S-UX, used for parameter configuration, operation mode switching and running status monitoring.
- Display Screen: Shows real-time operating data including current, voltage, frequency and fault codes.
______________________________________________________________________________________________
Input/Output Interfaces:
- Power Input: Connects to 380/480V three-phase power supply.
- Motor Output: Connects to three-phase induction motors.
- Control Signal Terminals: Supports external wiring including input/output relays and analog input terminals for remote control and system integration.
Cooling System: Built-in high-performance cooling fan maintains stable operating temperature even under high-load conditions, preventing overheating and extending service life.
______________________________________________________________________________________________
Typical Applications
- HVAC Systems: Air conditioning compressors, fan motors and central air conditioning equipment.
- Pumping Systems: Water supply pumps, circulation pumps and chemical pumps.
- Ventilation & Fans: Industrial ventilation systems and roof exhaust fans.
- Light Machinery: Packaging machines, conveyors and textile machinery.
______________________________________________________________________________________________
Installation & Maintenance Recommendations
Installation Notes
- Mounting: Secure the drive to a wall or base using shock-absorbing pads to reduce vibration transmission and ensure stable operation.
- Cooling Space: Leave sufficient clearance (approximately 75mm) around the drive for smooth ventilation, and keep the air outlet unobstructed at all times.
- Cable Routing: Separate power cables from control cables; route output power cables and input control cables apart to avoid electromagnetic interference.
- Grounding: Follow the instruction manual strictly for proper grounding to prevent static buildup and ensure operational safety.
Maintenance Tips
- Regular Inspections: Check the tightness of power cables and connection terminals at least once a year to avoid loose connections and potential failures.
- Fan Cleaning: Remove dust from fan blades and cooling vents regularly to keep the cooling system efficient and prevent overheating faults.
- Troubleshooting: Refer to the instruction manual and use the fault codes displayed on the keypad (such as E1, E2) for quick fault diagnosis and resolution.
————————————————————————————————————-
