1. Overview

2. Specification Parameters

3. Product Features

• Efficient Control: Through the cross-connection of main contacts and auxiliary contacts, it can reliably realize the forward and reverse switching of the motor.
• High Reliability: Adopting GE high-quality contact materials and reliable contact design, it is suitable for long-term operation in industrial fields.
• Compact Design: As a Size 1 relay, it has a small volume, suitable for distribution cabinets or control boxes with limited space.
• Good Versatility: Standard DIN rail mounting method, strong compatibility, easy to combine with other electrical components of GE or third-party brands.

______________________________________________________________________________________________

4. Structure and Composition

• Main Contacts: Responsible for the on-off of the main circuit.
• Auxiliary Contacts: Usually include Normally Open (NO) and Normally Closed (NC) contacts, used for switching control signals and status indication.
• Coil: When the coil is energized, it generates a magnetic field to drive the contact switching.
• Housing: Usually a transparent or translucent plastic housing, which is convenient for visual inspection of contact status.
• DIN Rail Base: Used for mounting on DIN rails, providing mechanical support and electrical connection.

______________________________________________________________________________________________

5. Application Fields

• Water Pump Control: In water supply systems, it is often used to control the start, stop and forward/reverse rotation of water pumps to change the direction of water flow or perform drainage.
• Fan System: Used for the start-up and direction control of large fans.
• Industrial Conveyor: Control the forward and backward movement of the conveyor belt in the conveying system.
• HVAC System: Used for fan or compressor control in heating, ventilation and air conditioning systems.
• General Mechanical Equipment: Suitable for various small industrial machinery that requires forward and reverse motor control.

______________________________________________________________________________________________

6. Installation and Maintenance

Installation

• DIN Rail Installation: Slide the relay into the corresponding slot of the DIN rail to ensure it is properly clamped.
• Wiring: Connect the power line, load line (motor line) and control line (such as forward/reverse command line) according to the electrical diagram. Usually, it is necessary to connect a forward/reverse control switch or PLC output signal.
• Polarity Confirmation: Ensure the wiring polarity of the electromagnet coil is correct (usually AC line) to avoid non-action caused by reverse connection.

Maintenance

• Regular Inspection: Regularly check whether the wiring terminals of the relay are loose and whether the contacts have ablation marks.
• Cleaning: Remove dust and debris inside the housing to prevent impurities from entering the contacts.
• Protection: In humid or corrosive environments, it is recommended to install a protective box or use anti-corrosion coating.
• Replacement: When the contacts have obvious burning, adhesion or poor contact, the relay should be replaced with a new one in time.
