GE D20MIC10BASE-T 820-0756 modular component
GE D20MIC10BASE-T 820-0756
I. Product Overview
The GE D20 MIC 10BASE-T 820-0756 is a modular component specifically designed for industrial automation and control systems, suitable for the GE D20 series digital relay systems. It enables connection to external networks through the 10BASE-T Ethernet interface, supporting functions such as remote monitoring, data acquisition, and configuration.
II. Product Parameters
- Communication standard: 10BASE-T Ethernet, with a speed of 10 Mbps.
- Operating voltage: Supports dual voltage input of 24Vdc/120Vac.
- Interface type: RJ45 interface.
- Data transmission rate: Up to 10 Mbps.
- Operating temperature range: -40℃ to 85℃.
- Power supply: 5V DC.
- Dimensions: Approximately 400mm x 250mm x 150mm.
- Weight: 4-8kg.
- Protection class: IP20.
- Memory options: 0 MB, 8 MB, or 16 MB SRAM.
III. Product Features
- Power control core: Adopts Silicon Controlled Rectifier (SCR) technology, realizing precise regulation of current and power by triggering the SCR, suitable for controlling equipment such as resistance furnaces, electromagnets, and heating elements.
- Multi-dimensional monitoring capability: Integrates voltage, current, and temperature monitoring functions, which can feed back the circuit operation status in real-time to ensure that the equipment operates within safe parameter ranges.
- Flexible trigger control: Supports optimizing current waveforms by adjusting the SCR trigger angle, adapting to different load characteristics, and improving the flexibility and efficiency of power control.
- Industrial-grade communication interface: Equipped with a 10BASE-T Ethernet interface, supporting remote data transmission and monitoring, and can be seamlessly integrated with PLC systems and monitoring equipment to achieve remote management and automated control.
- High reliability and safety: Built-in overcurrent and overheating protection mechanisms, compliant with industrial standard certifications, ensuring stable operation of the equipment in complex industrial environments.
- Modular design: Supports function expansion and customization to meet diversified application needs.
- Compact and rugged design: Supports auto-negotiation and automatic MDI/MDIX, with built-in surge protection, suitable for industrial environments.
- Easy installation: Can be directly inserted into the slot of the D20 chassis, making installation convenient.
IV. Structure and Composition
The GE D20 MIC 10BASE-T 820-0756 module consists of the following parts:
- Main control chip: Responsible for handling power control and communication tasks.
- SCR control circuit: Used for precise control of current and power.
- 10BASE-T Ethernet interface: Used for data transmission and network connection.
- Protection circuit: Including overcurrent and overheating protection mechanisms to ensure safe operation of the equipment.
- Power module: Provides a stable 5V DC power supply.
V. Application Fields
- Power equipment control: Used for power regulation of equipment such as resistance furnaces and electromagnets to improve production efficiency.
- Industrial automation systems: Integrated into production lines and equipment monitoring systems to realize real-time monitoring and control of power parameters.
- Remote monitoring and management: Supports remote data transmission through the Ethernet interface, facilitating centralized management and fault diagnosis.
- Laboratory equipment: Used to control and monitor experimental equipment to ensure the accuracy of experimental parameters.
- Manufacturing automation: In large manufacturing plants, this module has been effectively implemented to facilitate precise control of machinery, thereby increasing productivity and reducing maintenance costs.
- Water treatment: In wastewater treatment facilities, the module is used for reliable data transmission to ensure the monitoring and control of various processes.
VI. Installation and Maintenance
Installation Methods:
- DIN rail mounting: Suitable for industrial environments, facilitating installation and maintenance.
- Direct insertion into the D20 chassis slot: Easy to install without additional tools.
Grounding Requirements:
- Low-impedance grounding: Use braided cable or heavy-duty solid copper conductors (12 AWG recommended) to ensure shunting of transient currents from the line to the ground.
- Clean grounding surfaces: Ensure all surfaces used for grounding are free of dirt, residues, and corrosion.
Maintenance Recommendations:
- Regular inspection: Regularly check connectors and grounding wires to ensure good connections.
- Environmental adaptability: Ensure the equipment operates within the specified temperature range to avoid the impact of extreme environments.
- Fault diagnosis: Use the diagnostic tools provided by the module to quickly identify and solve potential problems.
————————————————————————————————————-
