GE DS200PCCAG5ACB Power Connection Card
GE DS200PCCAG5ACB
I. General Description
The GE DS200PCCAG5ACB is a Power Connection Card (PCCA) manufactured by General Electric (GE), and it is part of the Mark V series control system. This module is primarily used to connect the SCR (Silicon Controlled Rectifier) power bridge to the control circuit of the driver, serving as a key component in industrial automation systems. It plays a crucial role in high-horsepower drives and complex industrial applications, with wide usage particularly in industries such as power, petroleum, chemical, and metallurgy.
II. Parameters
Based on available data, the specific parameters of the GE DS200PCCAG5ACB are as follows:
- Model: DS200PCCAG5ACB
- Manufacturer: General Electric (GE)
- Product Type: Power Connection Card (PCCA)
- Function: Connects the SCR power bridge to the driver’s control circuit, providing power supply, signal isolation, and protection functions
- Dimensions: Approximately 16cm × 16cm × 12cm (specific dimensions may vary slightly by version)
- Weight: Approximately 0.8kg (specific weight may vary slightly by version)
- Operating Temperature: -40°C to 85°C (specific temperature range may vary slightly by version)
- Input Voltage: 100-240VAC (specific input voltage range may vary slightly by version)
- Output Voltage: 0-10VDC (specific output voltage range may vary slightly by version)
- Maximum Current: 5A (specific maximum current may vary slightly by version)
- Communication Interfaces: Modbus, Ethernet (specific communication interfaces may vary slightly by version)
III. Product Features
- High Reliability: Adopts an industrial-grade design, suitable for harsh industrial environments, with high reliability and stability.
- Modular Design: The modular design facilitates installation and maintenance, as well as system integration and expansion.
- High Horsepower Adaptation: Specifically designed for high-horsepower drives, suitable for stable operation under high-load conditions.
- Pulse Transformer Connection: Feeds gate drives to the SCR bridge through a pulse transformer to achieve precise control.
- De-buffer Design: Removes all buffers and relocates them to other positions in the system, simplifying the design and improving efficiency.
- Jumper Configuration: Provides multiple jumpers (WP4, WP3, JP2, JP1) for circuit connection and configuration.
- Multi-protocol Support: Supports multiple communication protocols such as Modbus and Ethernet, facilitating integration with different systems.
IV. Structure and Composition
- Power Connection: Provides power connections to supply the required DC power to the driver, enabling the motor to operate.
- Signal Isolation: Achieves signal isolation through pulse transformers to enhance system safety.
- Protection Functions: Equipped with overcurrent, overvoltage, and other protection functions to prevent system damage.
- Modular Design: The modular design simplifies installation and maintenance, and facilitates system integration and expansion.
- Connectors: Features 12 plug connectors for providing forward and reverse gate pulse signals to the SCR bridge and supporting communication with the power board.
V. Application Fields
- Power Industry: Widely used in power plants, power system control, steam turbines, gas turbines, etc.
- Industrial Automation: Applied in industrial automation control systems, such as manufacturing, energy, transportation, etc.
- High-reliability Applications: Suitable for industrial applications requiring high reliability and precise control, such as petroleum, chemical, and metallurgy industries.
VI. Installation and Maintenance
- Installation: The modular design allows for easy installation and maintenance. It is typically installed at the rear of the drive control board and fixed in the bracket via plastic supports.
- Maintenance: Regularly check the power supply and communication connections to ensure the module operates normally.
- Notes: Follow the manufacturer’s guidelines to ensure compatibility, comply with environmental conditions and safety operating procedures, so as to guarantee the safety of personnel and equipment.
————————————————————————————————————-
