GE DS200QTBAG1A Turbine Interface Board
GE DS200QTBAG1A
Overview
Reliable signal connections are essential for turbine control and monitoring. The GE DS200QTBAG1A serves as an RST termination board within compatible Mark V control cabinets. It connects field wiring with designated control-system interfaces, helping organize the signals required for turbine operation and monitoring.
Product Highlights
- Provides field wiring termination for compatible turbine control systems.
- Supports magnetic pickup inputs for speed-related measurements.
- Interfaces with servo output and LVDT excitation circuits.
- Includes COREBUS and IONET communication connections.
- Offers a serial monitoring connection for diagnostic support.
Hardware Specifications
The DS200QTBAG1A features two terminal blocks, identified as TB1 and TB2, with 72 terminals per block. Its connector arrangement includes interfaces for COREBUS, STCA and TCQC board signals, servo-related signals, and RS-232 monitoring.
The exact wiring assignments and jumper configuration depend on the installed system. Always refer to the applicable technical manual before making connections.
Industrial Uses
This board is intended for compatible GE Mark V turbine control installations. It may be required during scheduled maintenance, fault diagnosis, control cabinet refurbishment, or replacement of a damaged termination assembly.
Keeping suitable spare parts available can help maintenance teams restore existing equipment efficiently. However, the replacement board must match the original hardware requirements.
Maintenance Guidelines
- Record the full model and revision markings.
- Label all wires and connectors before disassembly.
- Inspect terminals for corrosion, looseness, or damage.
- Verify jumper settings and wiring against the system drawings.
- Complete the required functional checks before returning the equipment to service.
Never replace the board while the cabinet is energized unless an approved procedure explicitly permits the operation.
