GE DS200SHVMG1AGE Control Module
GE DS200SHVMG1AGE
I. Overview
DS200SHVMG1AGE is a key component in the GE Mark V series control systems. It is mainly used to achieve precise control of servo motors and provide high-precision signal processing and interface functions in the fields of industrial automation and process control. This module is widely applied in scenarios requiring high reliability and high-precision control, such as power plants, industrial production lines, and power systems.
II. Parameters
- Model: DS200SHVMG1AGE
- Brand: General Electric (GE)
- Type: Servo drive module / High-voltage M-frame interface board / Digital input-output module
- Input voltage: AC 115~230V, DC 12V/24V
- Output voltage: 0-220V AC
- Frequency range: 0-400Hz
- Control accuracy: Speed control accuracy ≤0.5%, torque control accuracy ≤3%
- Acceleration and deceleration time: 0.1-3600 seconds
- Communication interfaces: Supports Ethernet, serial, USB, etc.
- Operating temperature: 0℃~50℃ (operating), -40℃~65℃ (storage)
- Dimensions: 150mm (width) x 140mm (depth) x 86mm (height) (slight variations may exist for specific models)
- Weight: Approximately 2KG (slight variations may exist for specific models)
- Protection class: IP20 (standard industrial protection class)
III. Product Features
- High-precision control: Capable of precisely controlling the speed and torque of servo motors, suitable for industrial equipment requiring high-precision positioning.
- Modular design: Facilitates installation, maintenance, and replacement, allowing users to flexibly configure the system according to actual needs.
- High reliability: Adopts industrial-grade components, featuring strong anti-interference capability and stability, suitable for harsh industrial environments.
- Versatility: Supports connection with multiple sensors, applicable to different industrial application scenarios.
- Safety protection: Equipped with multiple protection functions such as overcurrent, overvoltage, short circuit, and overheating to ensure safe operation of equipment.
- Compatibility: Specifically designed for the GE Mark V system, enabling seamless integration with other Mark V components.
- Digital and analog signal processing: Can process analog and digital signals from sensors, supporting multiple input configurations.
IV. Structure and Composition
DS200SHVMG1AGE typically consists of the following parts:
- Circuit board: 7 x 9.5 inches in size, with 17 jumpers (JP1 to JP18), 6 2-pin connectors, and 2 4-pin connectors.
- Jumpers and connectors: Used to configure parameters such as signal attenuation and current conversion.
- Cooling system: Equipped with an 80 x 80mm fan for heat dissipation.
- Power module: Supports AC and DC input, with PFC (Power Factor Correction) function, complying with the EN61000-3-2 standard.
- Signal conversion module: Can convert high-voltage signals to low-voltage signals, suitable for industrial automation and process control.
V. Application Fields
DS200SHVMG1AGE is widely used in the following fields:
- Industrial automation: Used to control the movement of equipment such as robots, packaging machines, and machine tools.
- Power industry: Used for monitoring and controlling equipment in power plants, such as generators, boilers, and turbines.
- Energy management systems: Used to monitor and control the operating status of power systems, ensuring stable and safe power supply.
- Manufacturing: Used for automated control in production lines to improve production efficiency and product quality.
- Transportation: Applied in traffic signal control, vehicle scheduling, etc.
- Building automation: Used in building automation systems, such as centralized control of air conditioning, lighting, security, and other equipment.
VI. Installation and Maintenance
Installation:
- DS200SHVMG1AGE is usually installed in control cabinets or racks. It is necessary to follow the manufacturer’s installation guidelines to ensure compatibility and stability.
- During installation, attention should be paid to the stability of power input and output, as well as the connection status of signal interfaces.
- Since the product is related to power systems, installation and maintenance should be performed by qualified professionals.
Maintenance:
- Regularly check the stability of power input and output, as well as the connection status of signal interfaces.
- Keep the equipment clean to prevent dust and moisture from entering.
- Conduct regular calibration and testing to ensure the normal operation of the equipment.
————————————————————————————————————-
