GE DS200TBQBG1A CB Analog I/O Terminal Board
GE DS200TBQBG1A CB
Product Overview
The GE DS200TBQBG1A CB is an analog I/O termination board associated with the GE Mark V Speedtronic turbine control system. It provides an interface for field signals, helping route measurement data from sensors and transmitters to the corresponding control boards.
The board supports signal connections for analog measurements, vibration monitoring, and pulse-rate inputs. These functions help the turbine control system collect operating information and coordinate monitoring and control tasks.
Technical Parameters
| Parameter | Description |
|---|---|
| Brand | General Electric (GE) |
| Model | DS200TBQBG1A CB |
| Product Type | Analog I/O Termination Board |
| Functional Acronym | TBQB |
| Compatible System | Mark V Speedtronic |
| Main Function | Field signal termination and routing |
| Signal Types | Analog, vibration, and pulse-rate inputs |
| Main Connectors | JGR and JHR |
| Configuration | Hardware jumpers |
Key Features
- Multiple signal interfaces: Supports connections for different types of field measurements.
- Organized signal routing: Transfers designated input signals to compatible control boards.
- Configurable analog inputs: Hardware jumpers support selected input configurations.
- Industrial control integration: Designed for use within compatible turbine control cabinets.
- Practical maintenance: Clearly identified connectors and configuration points assist inspection and troubleshooting.
Structure and Applications
The board uses a printed circuit assembly with signal connections, routing circuitry, and hardware configuration points. In a compatible Mark V installation, the JGR connector routes analog and vibration signals toward the TCQA board, while JHR handles designated pulse-rate and compressor-stall detection signals for the TCQC board.
Typical applications include:
- Gas and steam turbine control
- Turbine vibration monitoring
- Compressor operating-condition monitoring
- Industrial power generation
- Field instrumentation signal integration
Installation and Maintenance
Before installation, confirm the complete part number, revision, and required jumper settings. Disconnect power according to the equipment manufacturer’s procedures and observe electrostatic discharge precautions.
During routine maintenance, inspect terminal connections, connectors, and circuit-board surfaces for looseness, contamination, or damage. Verify signal routing and hardware settings against the applicable GE documentation before returning the system to service.
————————————————————————————————————-
