GE DS200TBQCG1AAA Terminal Board
GE DS200TBQCG1AAA
Product Overview
The GE DS200TBQCG1AAA is a dedicated Termination Board for GE’s Mark VIe gas turbine control system, serving as a critical interface component of the Speedtronic™ series. As a hub for signal distribution and wiring, this module primarily connects field sensors (such as thermocouples, RTDs, and 4-20mA transmitters) to Mark VIe control modules (e.g., IS200 series I/O modules), providing a safe and reliable signal transition.
The DS200TBQCG1AAA features a high-density terminal design, supporting centralized distribution of analog and digital signals, with built-in signal conditioning and protection circuits (e.g., TVS diodes, fuses). Its modular structure facilitates maintenance, allowing quick replacement without disrupting system operation, making it suitable for temperature, pressure, and vibration monitoring systems in gas turbines and steam turbines.
Product Parameters
- Product Model: DS200TBQCG1AAA
- Manufacturer: GE Energy (Mark VIe series)
- Product Type: Signal termination board
- Compatible Signals: Thermocouples (Type K/J/E), RTDs (PT100), 4-20mA, dry contacts
- Terminal Quantity: 64 points (expandable)
- Wiring Specification: Supports 0.5-2.5mm² wire diameter
- Isolation Voltage: 1000V AC (between channel groups)
- Protection Circuit: TVS surge protection, self-recovery fuse
- Operating Temperature: -20°C ~ +60°C
- Protection Class: IP20 (must be installed in control cabinet)
- Compatible Systems: GE Mark VIe / EX2100e
- Installation Method: DIN-35mm rail mounting
Structure and Composition
The DS200TBQCG1AAA consists of the following core components:
Terminal Block Layer
- High-density spring terminals, divided into 4 groups (16 points per group), supporting mixed connection of thermocouple, RTD, and current signals.
- Each group of terminals is equipped with an independent identification slot to prevent wiring errors.
Signal Protection Layer
- Thermocouple input channels have built-in cold junction compensation circuits.
- 4-20mA loops integrate 250Ω precision resistors (for voltage conversion).
- Digital input channels feature optocoupler isolation (1500V AC).
Backplane Interface Layer
- Connected to Mark VIe I/O modules (e.g., IS200TBAIH1C) via ribbon cables.
- Plug-in connector design supports quick replacement.
Key Features and Advantages
Signal Integrity Assurance
- Low thermoelectric potential terminal material (tin-plated copper) reduces thermocouple measurement errors.
- Dedicated grounding terminals for shielding layers to suppress high-frequency interference.
Safety Protection Design
- Each channel is equipped with a TVS tube (600W transient suppression), passing IEC 61000-4-5 surge tests.
- Self-recovery fuses prevent damage to backend modules due to wiring short circuits.
- Terminal quantity can be increased via the DS200TBCG1A expansion board.
- Supports custom jumper configurations (e.g., RTD 2-wire/3-wire switching).
Maintenance Friendliness
- Terminal blocks can be disassembled as a whole for easy line inspection.
- Transparent dust cover design balances protection and visibility.
Application Fields
Gas Turbine Monitoring Systems
- Distribution of exhaust thermocouple (TTRF) signals.
- Wiring transition for bearing vibration sensors (4-20mA).
Steam Turbine Protection
- Integration of condenser vacuum switch (dry contact) signals.
- Implementation of OPC protection in conjunction with the IS200VSVOH1B module.
Power Plant DCS Interface
- Distribution of field signals to Mark VIe and third-party systems (e.g., Siemens PCS7).
Related Products
- IS200TBAIH1C: Analog input module, directly connected to the terminal board.
- DS200TBCG1A: Terminal expansion board, adding 64 wiring points.
- DS200PSAG: Mark VIe rack power supply, providing power for the terminal board.
- IS200ERMG: Fiber optic communication card for long-distance signal transmission.
- EX2100e: Excitation control system, compatible with this terminal board.
Installation and Maintenance
Pre-Installation Preparation
- Use a torque screwdriver (0.6N·m) to fasten terminals to avoid loose connections.
- Check that the ribbon cable plug latches are intact to prevent loosening due to vibration.
- Install equipotential grounding rings for thermocouple channels to eliminate ground loop interference.
Maintenance Recommendations
- Measure terminal contact resistance annually (should be <10mΩ).
- Regularly clean terminal oxide layers (using DeoxIT® cleaner).
- Mark wire number sequences during replacement to avoid re-wiring errors.
————————————————————————————————————-
