1. Overview & Positioning

2. Technical Parameters

3. Core Product Features

• Modularity & Flexibility: Adopting a plug-and-pull design, it enables quick on-site replacement and maintenance, and supports hot plug operation for uninterrupted system work.
• High Reliability: Integrated with a fast-acting fusible link, it can quickly cut off the current in case of overcurrent or short-circuit faults, effectively protecting downstream electrical equipment from damage.
• Compact Size: Designed for EU standard DIN rail mounting, its compact structure is highly suitable for high-density power distribution cabinet layouts, optimizing cabinet space utilization.
• Standard Compliance: Fully complies with the international IEC 60269-1 standard and DIN 60304 standard, ensuring product performance, safety and universal compatibility.

______________________________________________________________________________________________

4. Structure & Components

• Metal Enclosure: Provides robust mechanical protection for internal parts and fulfills the grounding function to enhance electrical safety.
• Insulator: Normally made of ceramic or heat-sealed insulating material, which effectively prevents electric arcs and short circuits, isolating live components.
• Fuse: Built-in thermal fuse, serving as the core component to realize overcurrent and short-circuit protection, cutting off faulty circuits timely.
• Contact Sheet: Responsible for current conduction, equipped with multiple contact points to ensure low contact resistance and stable power transmission.
• Terminal: Used for busbar connection, available in bolt-type terminals or spring-loaded terminals to meet different installation demands.

______________________________________________________________________________________________

5. Main Application Fields

• Power Distribution Systems: Busbar protection and connection inside power distribution cabinets and switchgears.
• Industrial Automation: Power distribution in PLC control cabinets and frequency converter control cabinets.
• Building Facilities: Computer room power distribution systems in large-scale buildings and commercial complexes.
• Other Low-Voltage Distribution Scenarios: Auxiliary power distribution in industries such as rail transit, petrochemical engineering, and power plants.

______________________________________________________________________________________________

6. Installation & Maintenance Recommendations

• Installation Orientation: Correctly distinguish the power bus and load bus before installation; the two are generally marked with color coding (red for power supply, blue for load).
• Fixing Method: Secure the product to the DIN rail with bolts or spring clips, ensuring tight and reliable contact to avoid poor conduction or loosening.
• Inspection Points: Regularly check the integrity of the fuse, and inspect whether the terminals are loose or oxidized to eliminate potential safety hazards.
• Replacement Operation: Conduct replacement only under power-off conditions, and verify that the rated current of the newly installed bus plug matches the system parameters to ensure operational safety.
