GE HEA61B238-X2 Electrical Relay
GE HEA61B238-X2
1. Overview
GE HEA61B238-X2 is a high-performance electrical relay, commonly used in industrial electrical control systems. This model belongs to GE’s HEA61 series and is usually applied in occasions requiring high reliability and precise control, featuring a compact structure and excellent electrical characteristics.
______________________________________________________________________________________________
2. Key Parameters
- Voltage Rating: 100VDC (Direct Current Voltage)
- Current Specification: 2A (Typical Value)
- Power Dissipation: 2W
- Structure Type: NSFS (Non-Standard Form Factor)
- Operating Temperature Range: -30℃ – 85℃ (Suitable for Harsh Environments)
- Overall Dimensions: Miniaturized relay design, suitable for panel mounting.
______________________________________________________________________________________________
3. Product Features
- High Reliability: As a world-renowned brand, GE’s relays perform excellently in terms of service life and performance stability, suitable for high-intensity working environments.
- Compact Design: Adopting Non-Standard Form Factor (NSFS), it is small in size and suitable for installation on control cabinets or panels with limited space.
- Low Power Consumption: The operating power is only 2W, with low energy consumption and little heat generation.
- Wide Compatibility: This model is usually used with other models of GE HEA61 series (such as HEA61A235-X2), featuring good compatibility.
______________________________________________________________________________________________
4. Structure and Composition
- Coil Assembly: Responsible for generating magnetic field after power-on to realize switching action.
- Contact System: Including Normally Open (NO) contacts and Normally Closed (NC) contacts, used to control the on-off of the circuit.
- Housing: Adopting NSFS structure to provide physical protection and electrical insulation.
- Terminals: Used to connect power lines and load lines, usually adopting screw-type or snap-on connection.
______________________________________________________________________________________________
5. Application Fields
- Motor Control Systems: Used for starting, stopping and protecting motor operation.
- Industrial Instruments: Used as a protection relay to monitor circuit status.
- Automation Equipment: Used for robot control panels and automated production lines.
- Energy Management: Used for shunting and overload protection in power distribution cabinets.
______________________________________________________________________________________________
6. Installation and Maintenance Recommendations
- Installation Direction: Usually marked with “NO/NC” indication direction, ensuring that it is consistent with the circuit diagram during installation.
- Wiring: Ensure that the wiring terminals are fastened to prevent poor contact caused by vibration.
- Operating Environment: Try to avoid humid and highly corrosive environments and keep ventilation.
- Maintenance: Regularly check the contact status and coil resistance of the relay to prevent poor contact caused by aging.
————————————————————————————————————-
If you would like to learn more about our products and services, please feel free to contact us at any time!
- Sales Manager : Jinny
- Email : sales5@xrjdcs.com
- Whatsapp/Mobile:+86 15359273791
