GE IC693TCM302B Temperature Control Module
GE IC693TCM302B
Product Overview
The GE Fanuc IC693TCM302B is a temperature control module designed for the Series 90-30 PLC platform. It provides multi-zone temperature regulation by processing thermocouple signals and controlling external heating equipment. With dedicated control functions, the module can manage temperature loops without requiring the main PLC CPU to perform every temperature-control calculation.
This module suits industrial processes that require consistent thermal conditions, reliable feedback, and coordinated control across multiple heating zones.
Technical Specifications
| Parameter | Description |
|---|---|
| Manufacturer | GE Fanuc |
| Model | IC693TCM302B |
| Product Type | Temperature Control Module |
| PLC Platform | Series 90-30 |
| Input Channels | 8 thermocouple inputs |
| Output Channels | 8 solid-state DC outputs |
| Control Modes | Open-loop and closed-loop |
| Control Function | PID and temperature regulation |
| Backplane Power | 5 VDC |
| External Output Supply | 18–36 VDC, subject to specifications |
Specifications should be confirmed against the documentation for the exact hardware revision before installation.
Main Features
- Multi-zone temperature control: Supports up to eight temperature-control channels.
- Automatic regulation: PID control helps maintain the required process temperature.
- Thermocouple signal processing: Receives temperature feedback from compatible sensors.
- Dedicated output channels: Controls external devices through solid-state DC outputs.
- Diagnostic support: Status indicators help technicians identify operating conditions and potential faults.
Applications
The module can be used in industrial ovens, packaging machinery, plastics processing, heat-treatment equipment, and production lines requiring several independently controlled temperature zones.
Installation and Maintenance
Install the module in a compatible Series 90-30 rack and follow the approved wiring diagrams. Verify thermocouple polarity, field power requirements, output connections, and control parameters before commissioning.
For maintenance, inspect connectors, wiring, and status indicators regularly. If temperature readings fluctuate or outputs fail to respond, check the sensors, field supply, and configuration before replacing the module.
————————————————————————————————————-
